Help CenterFireproof Calcium Silicate Ceiling Board
Related Products
Specifications
fireproof Calcium Silicate Ceiling Board1.high density,heat-preventing
2.fireproof,quakeproof
3.waterproof
4.long service
fireproof Calcium Silicate Ceiling Board is mainly made from silicious material, lime fractory and reforcing fiber through the process of slurrying,forming,high pressure steam curing, drying, surfacing and so on.
Category:Plane Printing Series,Sculpture Series, Embossment Series,Dream Colour Series and Perforating Series
Physical properties of fireproof Calcium Silicate Ceiling Board
Properties |
Data |
Materials |
silicate, quartz sand, plant fiber, etc. |
Design |
various |
Fireproofing features |
Incombustible A-class material (GB8624-1997) |
Refractory High-point |
4.0 hours (GB/T9978-1999) |
Bulk density |
1.2-1.6 g/cm3 |
Moisture content |
<10% |
Sound insulation |
45db (GBJ75-84) |
Edge |
square or bevelled |
Wet-inflation rate |
<0.17% |
Shrinkage rate |
<0.08% (GB/T7019-1997) |
Radioactivity: |
conform to GB6566-2001A Class |
Pull-out strength of screw |
≥95.4N/mm |
Anti-bend strength |
≥13Mpa |
Secification of fireproof Calcium Silicate Ceiling Board :
595mm*595mm*(4-6mm)
600mm*600mm*(4-6mm)
603mm*603mm*(4-6mm)
Applications of fireproof Calcium Silicate Ceiling Board :
suspended ceiling,fireproof board. It can be used for: Commercial and industrial construction,residential buidling, movie theaters, exhibition halls, restaurants, hotels, hospitals, train station or MRT stations and so on.
Packing of fireproof Calcium Silicate Ceiling Board in cartons or in bulk
