Home > Products > Plastic mixer unit > horizontal mixers
horizontal mixers
- 1 Set / Sets per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
-
Good price industrial small vertical plastic granules color mixer supplier
-
Good price 304 stainless steel horizontal food powder mixer supplier
-
Good Price Vertical Screw Type Plastic Drying Mixing Machine Mixer with Dryer
-
Good Price Plastic Material batch Mixer Gravimetric Blender Machine Supplier
-
Industrial Double Screw Metering Mixer Volumetric Doser
-
500 kg capacity mixer/ vertical plastic granules mixer
Product Details
Condition: | New | Application: | plastics | Automatic Grade: | Automatic |
Production Capacity: | 200kg/h | Place of Origin: | Jiangsu, China | Brand Name: | REUSING |
Model Number: | SRL-W | Voltage: | 380V,50HZ,3-PHASE | Power(W): | 4-22kw |
Dimension(L*W*H): | 2500*2100*3800 Mm | Weight: | 450kg | Certification: | CE,ISO |
Warranty: | ONE YEAR | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
horizontal mixers,wood plastic mixer machinery,wood plastic mixer machine,wood plastic mixer equipment,wood plastic mixer device,wood plastic mixing device,wood plastic mixing equipment,wood plastic mixing machine,wood plastic mixing machinery.
Specifications
Plastic hot Mixer/plastic cold mixer/PVC mixer/heating mixer/cooling mixer
1. High capacity
2. Easy to operation
3. has state patent NO.ZLP62430641
4. SS304 material
5. Certification: ISO9001:2000 CE
FEATURE AND FUNCTION:
- SRL-W series mixer unit is widely used in mixing, drying, coloring and other processing. It is the most ideal equipment for producing shaped plastic material and plastics pipes.
- The technology of the main shaft sealed apparatus has got the state patent with NO.ZLP62430641 and it has two functions of electric and steam heating.
- Two layers of sealing technology is adopted in the pot cover. The opening of the heating mixed cover adopted the air opening device and the opening of the cooling mixed cover adopted hydraulic pressure control system.
- The electric control section with the programmable logic control adopted well-know imported meters and components.
- It is equipped with the pulse dust-cleaning recovery device.
- The blades have been passed the test of the dynamic and static balance testing machines.
- You may choose the simple and easy feeding system.
Main Technical Parameters
Model | Total volume(L) | Effective volume (L) | Motor power (KW) | Main shaft speed(rpm) | Heating time (min/pot) | Cooling time (min/pot) |
SRL-W500/2000 | 500/2000 | 375/1200 | 55/75-18.5 | 430/860-80 | 8-10 | 6-8 |
SRL-W800/2500 | 800/2500 | 560/1024 | 83/110-22 | 357/714-80 | 8-12 | 6-10 |
SRL-W1000/3500 | 1000/3500 | 700/2000 | 110/160-37 | 325/650-80 | 8-12 | 6-10 |
SRL-W1300/4500 | 1300/4500 | 910/2450 | 132/200-37 | 300/600-60 | 8-12 | 6-10 |
HERE IS OUR CERTIFICATION FOR YOUR REFERENCE:
OUR COMPANY HISTORY:
OUR CONTAINER SHIPPING:
COMPANY EXHIBITION:
Contact Us
- Zhangjiagang Lianguan Recycling Science Technology Co., Ltd.
- Contact nameA-Zhiping Bao
- Phone0086-0512-58516000
- AddressNo. 585, Yangjin Road, Jinfeng Town, Zhangjiagang
-
