plastic mixer

Specifications

plastic mixer
1, good balance
2, no material leaking, with national patent
3, strong structure
4, kinds of model

 Production Name:  plastic mixer



Description & Consist of:

the  plastic mixer is used in mixing, drying, colouring and other processing, It is the most ideal equipment for producing shaped plastic profiles and pipes.



Properties:



1, for mixing plastic power, plastic granule with fomular ingrediants in production of plastic profile and pipes;

2, sealing of mainshaft with national patent(No.ZLP6243064), ensure no material leaking in 3 years at least;

3, two layers of sealing technology is adopted in the pot cover, cover opening of hot mixer is pneumatically,  and use hydraulic system for cover opening of cooling mixer;

4, imported control components and meters are used for auto-control;

5, pulse de-dust system is optional to this mixing system;

6, the paddles have been passed the test of dynamic and static balance testing, with good performance;

7, two heating way: by electricity or by steam.



Available models at present

model	total volume(L)	efftive volume(L)	motor(kw)	time(m/batch)	apprent size(mm)	weight(kg)
SRL-Z50/100	50/100	32/75	7/11-5.5	8-10	2300/1800/1900	1800
SRL-Z100/200	100/200	75/160	14/22-7.5	8-10	2500/2000/2200	2500
SRL-Z200/500	200/500	150/320	30/42-11	8-10	4580/2240/2470	3600
SRL-Z300/600	300/600	200/360	40/55-11	8-10	4580/2240/2500	4500
SRL-Z300/1000	300/1000	200/640	40/55-11	8-10	4600/3000/4050	4900
SRL-Z500/1000	500/1000	375/650	55/75-18.5	8-10	4600/3000/4050	5800
SRL-Z500/1600	500/1600	375/1200	55/75-18.5	8-10	4600/3000/4050	6500
SRL-Z800/1600	800/1600	600/1024	83/110-22	8-12	6230/4230/4480	8300
SRL-Z800/2500	800/2500	600/1500	83/110-30	8-12	4850/3860/6550	8800
SRL-Z1000/3000	1000/3000	700/1800	110/160-37	8-12	4930/4150/6850	11500



Relative Photo





  Certificate



Our Advantage



1, Professional: As a leading machine Manufacturer, LianGuan Recycling offers the plastic

extruding, plastic recycling machine and WPC products, and  The close collaboration with

our sales and technical support teams.

2, History & reputation: in 55 years development, we have already cooperated with customers

from 10s countries and regions.

3, Good Quality&Service: We are dedicated to being the leader in providing quality products

and services which meet or exceed the expectations of our customers.

5, Delivery on time: our strict production plan and good shipping cooperator are the guarantee

for delivery on time.

6, OEM Accepted: we can produce the machines & WPC products with your designs.



What we are doing



1, Respect and Integrity:We treat our customers with respect and dignity.

2, Commitment to Customers: Passionate commitment to our customers' success though our

technology, innovation and solutions.

3, Working Direction: Our passion for creating value through innovation, agility, and an unrelenting

focus on our customers.

4, Innovation: We believe that innovation through our technology and the creativity of our people

powers our success and the success of our customers.





Company Ability Show
