Specifications
pvc extruder device,single screw extruder,twin screw extruder,it is mainly used to process pvc, pp, pe, absand others
pvc extruder device, single screw extruder, twin screw extruder, small plastic extruder, extruders for plastic, recycled plastic extruder, new plastic extruder, used plastic extruder, small extruder, recycle plastic extruder, plastic film extruder, concrete extruder, plastic pipe extruder, plastic extruder, plastic granular extruder, extruder for plastic pigment, plastic sheet extruder, plastic extruder machinery, tandem extruder, single extruder, mini plastic extruder, double extruder, plastic twin screw extruder.
This machine is mainly used to process pp, pe, abs and other plastics. Equipped with auxilary machines, it can manufacture profile, pipes, sheets and other plastic products and granulation. It has the advantage of simple production technological process, high output, stable quality and low cost.
SJZ Series conical double screw plastic extruders are special equipments which are suitable for various pvc powder to extrusion and molding. Equipped with different kinds of molds and auxiliary machines, it can produce kinds of pvc pipes, profiles, plates, bars and granulation.
model |
SJSZ45 |
SJSZ51 |
SJSZ55 |
SJSZ65 |
SJSZ80 |
Screw diameter mm |
Φ45/Φ90 |
Φ51/Φ105 |
Φ55/110 |
Φ65/132 |
Φ80/156 |
Effective length mm |
980 |
1070 |
1210 |
1430 |
1800 |
Screw speed r/min |
1~45 |
1~40 |
1~40 |
1~35 |
1~37 |
Motor power KW |
15 |
18.5 |
22 |
37 |
55 |
Barrel heating power KW |
10 |
12 |
18 |
24 |
36 |
Max output kg/h |
100 |
120 |
140 |
240 |
360 |
Central height mm |
1000 |
1000 |
1000 |
1000 |
1000 |
Weight kg |
3200 |
3300 |
3500 |
4000 |
5000 |
Dimension m |
3.4×1.3×2.1 |
3.5×1.3×2.1 |
3.6×1.4×2.1 |
4.2×1.5×2.4 |
4.7×1.5×2.4 |
model |
SJSZ92 |
Screw diameter mm |
Φ92/Φ188 |
Effective length mm |
2500 |
Screw speed r/min |
1~33 |
Motor power KW |
90 |
Barrel heating power KW |
86 |
Max output kg/h |
550 |
Central height mm |
1100 |
Weight kg |
8000 |
Dimension m |
6.5×1.6×2.8 |
