Help CenterDrum Chipper Wood Chipping Machine
Related Products
-
Wood Crusher Machine for Horse BeddingUS$ 1,000 - 9,500MOQ: 1 Unit -
Wood Shredder Crushing MachineUS$ 1,500 - 8,500MOQ: 1 Unit
-
Sawdust Crusher Machine, Wood Crushing MachineUS$ 1,000 - 9,000MOQ: 1 Set
-
Wood Crusher Machine/large Wood Slice MachineUS$ 1,000 - 9,000MOQ: 1 Set
-
New Type Wood Shaving Machine,wood Recycling Machine for SaleUS$ 2,000 - 5,000MOQ: 1 Unit
Specifications
1.wood shredder crusher2.big capacity ,with conveyors
4.drum type wood chipping machine
The main raw materials are cutting wood, wood cutting, paths using (such as the branches, branches, and the slab, attrib wattle, logs, waste veneer, etc), and it can also be used to cutting non-wood materials (such as sugar cane, reed, bamboo, etc.).
Hydraulic system: for the pump to oil cylinders, can start cover, facilitate blade replacement, In the maintenance can raise the feed roller assembly, easy adjustment, and the gap of the fly and comb of the board.
Model |
JX215 |
JX216 |
JX218 |
Feeding size(mm) |
160*400 |
230*500 |
300*680 |
Quantity fly_cutter (piece) |
2 |
2 |
2 |
Knife roll speed(turn) |
592 |
590 |
650 |
Maxmun diameter of the material(mm) |
160 |
230 |
300 |
Chipper size(mm) |
30 |
30 |
30 |
Capacity( T) |
3-4 |
7-8 |
12-15 |
Main moter power(kw) |
45 |
55 |
110 |
Feeding roll moter power(kw) |
2.2-3 |
3-4 |
4-5 |
oil pump moter power(kw) |
1.5*1 |
1.5*1 |
1.5*1 |
Weight(kg) |
2990 |
4070 |
7000 |
Overall dimensions(mm) |
1470*1550*970 |
1800*1900*1210 |
2200*2150*1500 |
Conveyor moter power(kw) |
3 |
3 |
3 |
