Specifications
Sawdust pallet machine/pallet block making machine1.we also have crusher,dryer,glue machine
2.single head and double head
Sawdust pallet machine/pallet block making machine
Equipment disposition:
Generally four hot presses are a production line, must provide the dryer, the gluing machine, grinder each. (Dryer, gluing machine, grinder and so on supporting facility customer buys in addition).
Personnel disposition: Production personnel are 4-5 people per shift. And raw material sort (screening), drying, spreads 2-3 people, looked that machine 2 people (a person may look at two machines).
Production cycle: After confirmation order form and payment advanced payment, 40 super craftsmanship factory delivery.
Equipment investment recoupment period: 10— 12 months.
Our factory is responsible for the technical training, and provides the consummation the post-sale service.
Technical data:
Specification model | Power input (KW) | Outlook size (mm) | Production efficiency (m3/24h) | Glue water amount used (kg/m3) | Supports the density (kg/m3) | Warm prosecution type | Complete machine weight (kg) |
MDJ75*75 | 13 | 5000*600*1300 | 2 | 100-120 | 550-600 | PID adjusts the merit accent to press the control | 1000 |
MDJ80*100 | 13 | 5000*600*1300 | 2 | 100-120 | 550-600 | 1000 | |
MDJ80*120 | 13 | 5000*600*1300 | 2.2 | 100-120 | 550-600 | 1050 | |
MDJ90*90 | 13 | 5000*600*1300 | 2 | 100-120 | 550-600 | 1000 | |
MDJ90*140 | 13.5 | 5000*600*1300 | 2.4 | 100-120 | 550-600 | 1100 | |
MDJ100*100 | 13 | 5000*600*1300 | 2.2 | 100-120 | 550-600 | 1050 | |
MDJ100*115 | 13 | 5000*600*1300 | 2.3 | 100-120 | 550-600 | 1080 | |
MDJ100*140 | 13.5 | 5000*600*1300 | 2.5 | 100-120 | 550-600 | 1120 | |
MDJ140*140 | 15 | 5000*600*1300 | 3 | 100-120 | 550-600 | 1350 |
