Product Details
Condition: | New | Type: | Stone Cutting Machine | Use: | Granite |
Place of Origin: | Shandong, China | Brand Name: | Huaxing | Model Number: | KJ80Y |
Certification: | CE | Warranty: | 1 YEAR | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
KJ80Y GANG SAW FOR MARBLE
Description
1.A blade stoke of 800mm facilitates the evacuation of slurry which results from the sawing of marble and, in particular, of non-crystalline materials, preventing the blades from clogging while ensuring a high quality cut. This is particularly important when sawing defective and fractured blocks.
An 800mm stroke also means fewer cycles/minute and consequently less mechanical stress on the relative components.
2. ARTICULATED RECTILINEAR GUIDES
Movement of blade holder frame on articulated
guides.
This system reduces to a minimum problem of
the blade holder frame.It greatly reduces maintenance
costs because it does not require replacement
like the traditional slideways which are subject to
continuous wear.
3. EQUAL DISTRIBUTION OF MECHANIXAL
THRUST OVER ALL MACHINE COMPONENTS
Advantages of two connecting rods:
· All the energy and mechanical thrust towards the blade holder is spread on two connecting rods and two cranks instead of just one.
· The two connecting rods which are attached to the extremes of the blade holder help the articulated guides to ensure that it’s movement remains perfectly rectilinear without any deviation. This is especially important when there are more blades on one side of the frame(the machine applies greater pressure where there are more blades),and when the blocks are of different heights(because initially more pressure would be applied on the higher block).
4.THE ROTATING LEAD NUTS which worm screws of the block trolley platform are situated above the columns and lubricated automatically.
5. BATTERY UNIT
Details of the battery unit. The battery supports have been designed to allow easy maintenance and facilitate the replacement of the roller bearings without having to break the cement foundations. The flywheel weights 8 tons and has a diameter of 3300mm
TECHNICAL DATA:
max.block size: | 3200(L)×2000(W)×2000(H)mm |
Blades number | 80 |
main motor power: | 110kw |
Up-down motor | 11kw |
Table motor | 1.5kw |
Transfer table motor | 1.5kw |
Saw frame reciprocating frequency | 90t/min |
Rotating speed of flying wheel | 90 rpm |
flying wheel shaft diameter | 280mm |
speed | 8-32cm/h |
stroke of the blades: | 800mm |
Up-down stroke | 2100mm |
blades length | 4400mm |
water consumption | 10L/min/blade |
total weight: | 55ton |
dimensions: | 12425 (L)×4700(W)×3800(H)mm |
STANDARD ACCESSORIES:
1 | pcs | Motorized block trolley, dimensions: 3.2x2.05m, carrying capacity: 30 tons. |
1 | pcs | Electrical control Board |
1 | sets | Hydraulic tensioner and oil pump |
80 | sets | Hydraulic hangers for blades |
160 | pcs | Blades spacers (choose one type from 22/32mm) |
8 | pcs | tightening chain |
4 | pcs | tightening plate |
1 | pcs | Dynametric Spanner |
