  HMSJ 180 Two-way Diamond Disc Stone Sawing Machine

This machine is mainly used for cutting the stone block of marble and soft granite.

Main Parameters:

1. Maximum diameter of vertical disc                                  1800mm

2. Maximum diameter of horizontal disc                              Φ600mm

3. Maximum cross stroke                                                  3600mm

4. Maximum vertical stroke                                                1600mm

5. Rotary speed of main shaft                                              633rpm; 504rpm

6. Maximum distance from axis of main shaft to trolley          2750mm

7. Area of trolley                                                              1700*1700mm

8. Size of stone block                                                    2500*1600*2000mm

9. Flow quantity of cooling water                                       ≥12m³/ h

10. Pressure of cooling water                                               ≥0.2Mpa

11. Total capacity                                                               93.4kw

Horizontal cutting up-down motor                                          0.55kw
