Potato starch plant centrifuge machine in starch production line
Centrifuge machine
Description of centrifuge machine:
SS800N model centrifuge machine is three-column top discharge centrifuge, which can be operated intermittently. It is one kind of general engineering products which do the gap operation. It is suitable for sharing suspending liquid which contains solid pellet ≥0.01 millimeter, such as granular, crystallization or textile fiber material separation. It is also used to make the textile dehydration and so on. Although SS is the manual dischange, but it has momentarily grasp the filtration time, and causes the filter residue to wash fully.Solid pellet is not destroyed and so on merits. It is widely suitable for chemical industry, drugs manufacture, food and light industry,and so on.At the same time, we can provide special specification centrifuge according to user's need.
Working principle of centrifuge machine:
Centrifuge machine is a kind of machinery which separate the suspending liquid and the emulsion solid and the liquid combination under the centrifugal force function.It contains the liquid is flung after on the filter medium and the rotor drum wall's hole the outer covering on the endophragm, after the collection, discharges by the filtrate export, but the solid phase keeps in the rotor drum, thus completes the centrifugal filtration.
Widely use dewatering technology for wheat starch, cassava starch, potato starch process. Stable capability, longevity service, stainless steel, fine overrall.
Main technical parameters of centrifuge machine:
Iterm |
Drum |
Power (kw) |
Separation factor |
Outer size (mm) |
Material |
||||
|
Dia. (mm) |
Height (mm) |
Input (kg) |
Rotation rate (r/min) |
Work capacity (t/h) |
|||||
SS800 |
800 |
400 |
115 |
1200 |
90 |
5.5 |
645 |
1740×1380×1000 |
Stainless steel, with motor |
The machine of starch production line:
1.Turn-key plants for the production of wheat starch, corn starch, potato starch and starch derivatives such as glucose, fructose, crystallized glucose, sorbitol, etc.
2.Professional engineers with ample on-the-job training experience.
3.Equipments are made of stainless steel, one year warranty, life-long maintenance.
We Sida Agricultural Products Equipment Co.,Ltd, is a special enterprise with research and development, production of agriculture products deep-processing complete equipment. Possessing fixed assets of RMB 6.6 million, covering an area of 33,335 square meters, with an annual production value of RMB 50 million, the company has got a lot of awards. Owned 11 national practical patents, it passed the accreditation of ISO90001 (international quality management system certification).
1. Q: If I want to know the price, what info should I provide?
A: You should inform us some basic info , such as: raw material, final product, input capacity or output capacity, specifiction of material and product, etc.
2. Q: If I already have a production line, can I add some machines to increase the capacity?
A: That's viable, pls contact us and we can help you find a suitable solution.
3. Q: How about the installation and commissioning?
A: We can send our engineers abroad for the supervision.
