20000 Liters milk flexitank transport

20000Liters olive oil flexitank transport

Capacity20,000Liters to 40,000Liters Muli ply PE+out PP bag

Loading/DischargingTop loading/discharging / Bottom loading/dischargingValve

1. Traditional 3" butterfly valve with anti-suction devise

2. Revolutionary 3" ball valve

a) Compared with butterfly valve, ball valve is sealed more tightly and with better resistance to pressure. There is no block when valve is opened, which make liquid flow through freely and quickly.

b) In the joint position between internal valve and flexitank, a safety protection device is added. This device could effectively prevent inner film blocking the valve, and make residual liquid the minimum after discharging.

3.valve with 2" or 2.5" quick connector for choice

FlangeHard PP instead of steel to reduce the pressure against the flexitank surface thus reduce the risk of failures.Safety PinAdded on 3” valve to help to source thefting activities if happened during transportation.Automatic Air ventThe special design of air vent could automatically release air pressure when it is more than 0.0065Mpa inside of the flexitank. It would keep the cargo and flexitank safe during loading and transportation.

Our engineers tracked and tested 1000 pieces of flexitanks at different transportation modes and conditions. We made those of the following revolutionary upgrading:

a)Protective out layer of BLT flexitank is 8m seamless tubular construction which would eliminate longitudinal seams.

b)Protective out layer of BLT flexitanks are made of high-tech aramid fibers, and it has incomparable advantage at tension and softness performance against ordinary PP fibers.

c)Each 10cm between woven of the protective layer, there is a high strength zonal reinforcing rib. Their application will make an innovative upgrade in the flexitank safety area.

Packing Capacity in Containers(20" & 40")

The features of our flexitank (Food Grade)

1)Quality Management

 Category

 Apply different flexitank materials to different liquid.

Flexitank—Food Grade

All the materials must comply with standards of food hygiene.

 Flexitank—For Oil

Proper for oils transportation

Heat-Resisting Flexitank

Apply heat-resisting materials,proper for the storage and transportation of high temperature liquid products.

  Application

In FLEXITANK it is possible to transport almost any of non-hazardous liquids,both industrial,and food application:

Foodstuff and Beverage:

Edible and animal oils and fats(liquid ands olid), juices concentrates,syrups,water,wine,honey,food additives,fish sauce,soy sauce,vinegar.

Industrial and Chemical:

Technical and industrial oils,chemical additives,water-reducer,liquid cleaning means,emulsions,glycerin,some kinds of paints,ink,liquid fertilizers,latex,transformer oils,other petrochemical products etc

What is flexitank?

A FLEXITANK (or called flexibag ) is a soft,tough ,light,polyethylene(PE) and polypropylene(PP).

Bladder with a volume of 20,000and 40,000 liters for the transportation of bulk non_hazardous liquid cargoes within a standard 20-foot ISO dry-box container,It is generally used one time. This makes flexitanks a cost-effective transportation solution for non-hazardous liquids,including certain chemicals,latex,wines,food oils and juices.

FLEXITANK should be installed in 20-foot container. Installation of a 20.000L FLEXITANK takes 10-20minutes. After installation you will just need to connect your connecting device to FLEXITANK. Using the pump you can start loading. Loading takes 20-40 minutes depending on type of a cargo and the pump. After loading is finished the container with FLEXITANK and your cargo is ready to travel. The flexitank can be transported by road,railway or sea.

Cost defective and considerably economical than ISO tank container,IBC and Drum

High payloads,Low weight and space.

No return,cleaning and demurrage cost.

Lower labor/time consuming for handling &loading.

Clean asepsis and no risk of contamination.

Environmental friendly.

No forklift required.

Can be rapidly positioned by airfreight if unrent needed.

Company Introduction
We are 3e Technology Co., Ltd. I saw the purchasing information of Edible Oil flexitank transport that you sent on , Actually we are Golden Supplier of more than 7 years.We specialized in manufacturing & exporting geomembranes since 1998, so far we had more than 13 years’ experience,materials including Muli ply PE+out PP bag ,HDPE, LDPE, LLDPE, EVA, ECB, PVC(all are no odor). thickness range from 0.15mm to 3.0mm , width range from 2m to 8m, or we can produce it at your request. Our geomembranes enjoy good popularity & reputation almost all over the world.
Our company motto is to provide best quality product at very reasonable price. So I hope the same from you because what I feel is quality conciousness is the key to success and long term business in market.
