Help CenterWashing Filling Capping Machine (3-in-1)
Related Products
Specifications
These series machines are mainly applied for the filling of beverage. Integrating with washing, filling and sealing, it realizesThese series machines are mainly applied for the filling of beverage. Integrating with washing, filling and sealing, it realizes full automation in the whole process, suitable for polyester bottle and plastic bottle filling of mineral water,purified water,juice and carbon dioxide drink or others beverage. The bottle types applicable for various parts are easily, conveniently and rapidly adjustable. It adopts new micro-negative pressure filling, stable and reliable. Compared with the machines of the same specification, the benefit of this machine is larger.
The machine adopts advanced OMRON programmable logic controller (PLC) to control the automatic running of the machine. The input bottle adopts air conveying device; the output bottle adopts adjustable speed way, which combines with the transducer of the host machine making the output bottle running more stable and reliable. The photoelectrical inspection of the running condition of various parts makes a higher automation and convenient operation. It is the ideal first-choice equipment of beverage manufacturers.
JR14-12-4 3000B/H Washing Filling Capping Machine (3-in-1)
Washing Workstation |
14 |
Filling Workstation |
12 |
Capping Workstation |
4 |
Production Capacity |
3,000B/H (500ml) |
Machine Power |
3kw |
Machine Weight |
4,000Kg |
External Dimensions (L*W*H) |
2,400 (mm)* 1,900 (mm) *2,800 (mm) |
JR16-16-5 6000B/H Washing Filling Capping Machine (3-in-1)
Washing Workstation |
16 |
Filling Workstation |
16 |
Capping Workstation |
5 |
Production Capacity |
5,000B/H (500ml) |
Machine Power |
3kw |
Machine Weight |
4,500Kg |
External Dimensions (L*W*H) |
2,500 (mm)* 1,900 (mm) *2,200 (mm) |
JR18-18-6 8000 B/H Washing Filling Capping Machine (3-in-1)
Washing Workstation |
18 |
Filling Workstation |
18 |
Capping Workstation |
6 |
Production Capacity |
8,000B/H (500ml) |
Machine Power |
3kw |
Machine Weight |
5,000Kg |
External Dimensions (L*W*H) |
2,800 (mm)* 2,050 (mm) *2,200 (mm) |
JR24-24-8 12000B/H Washing Filling Capping Machine (3-in-1)
Washing Workstation |
24 |
Filling Workstation |
24 |
Capping Workstation |
8 |
Production Capacity |
12,000B/H (500ml) |
Machine Power |
4kw |
Machine Weight |
7,000Kg |
External Dimensions (L*W*H) |
3,100 (mm)* 2,450 (mm) *2,800 (mm) |
JR32-32-10 15000B/H Washing Filling Capping Machine (3-in-1)
Washing Workstation |
32 |
Filling Workstation |
32 |
Capping Workstation |
10 |
Production Capacity |
15,000B/H (500ml) |
Machine Power |
5.5kw |
Machine Weight |
8,000Kg |
External Dimensions (L*W*H) |
3,700 (mm)* 2,750 (mm) *3,050 (mm) |
JR40-40-10 18000B/H Washing Filling Capping Machine (3-in-1)
Washing Workstation |
40 |
Filling Workstation |
40 |
Capping Workstation |
10 |
Production Capacity |
18,000B/H (500ml) |
Machine Power |
7.5kw |
Machine Weight |
9,500Kg |
External Dimensions (L*W*H) |
4,300 (mm)* 3,300 (mm) *2,900 (mm) |
