FIBER OPTICE CABLE

US$ 2,001 - 2,055 MOQ: 1 Kilometer

Key Specifications

Place of Origin:

Zhejiang, China

Model Number:

ITU-T G.652D

AHCOF International Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Model Number ITU-T G.652D

Items	Unit	Researched Technical Index
(Mode field diameter)	μm	9.2±0.4
(Mode field diameter)	μm	10.2±0.5
(Diameter of cladding)	μm	125±1
(Core-cladding concentricity error)	μm	≤0.6
(Cladding Non-circularity)	%	≤1.0
(Coating diameter)(uncolored)	μm	245±10
(Cladding- Coating concentricity error)	μm	≤12.5
(Cutoff wavelength of optical cable)	nm	≤1260

(Item)	(Unit)	(Researched Technical Index)
(Max. Attenuation coefficient at 1310nm)	dB/km	≤0.36
(Max. Attenuation coefficient at 1550nm)	dB/km	≤0.22
(Max. Attenuation coefficient at 1625nm)	dB/km	≤0.24
(Range of zero dispersion wavelength)	nm	1300~1324
((Max. zero dispersion slope)	ps/(nm2.km)	0.092
(Max. dispersion coefficient at 1550nm)	ps /(nm.km)	18
(Max. absolute dispersion coefficient at 1288~1339nm)	ps /(nm.km)	3.5
(Max. absolute dispersion coefficient at 1271~1360nm)	ps /(nm.km)	5.3

(Technical parameters)		(Researched Technical Index)
(Temporary allowed tensile force) N		≥1700
(Working tensile force) N		≥1000
(Temporary allowed anti-side compression tension) N/100mm		≥1000
(Weight) kg/km		226
(Outer diameter) mm		Φ16.7±0.3
(Allowed bending radius) mm	(During working)	160
	(During laying)	320
(Allowed operation temperature) ℃		-10~+70
(Water penetration)		(Optical cable of 3 m length has no water seapage with 1 m height of water column kept for 24h. )
(Impact) Nm		≥3
