Specifications
358 welded mesh security fencing1.anti-cutting
2.anti-climbing
3.high security anti climb fence
Brief instroducion
Compay Type:Manufacturer Head office:Anping County,China
Factory size:70,000sq.Meter nearest port:Tianjin,260km away
Sales Amount:US $30,000,000 per year lead time:20 days
Main Export Market:Austrilia,Europe,Japan,USA,South American,etc.
Main products:Security fence,Barrier fence,Temporary fence,wire mesh fence,T-post and ect.
WORKSHOP
358 ANTI-CLIMB FENCE
Formidable
An effective deterrent to intruder avaliable in height up 3.6m-specially designed for high security applications.
Panel
Manufactured form hard drawn wire and electro-resistance welded at every intersection.
Mesh Pattern:76.2mm(3'')*12.7mm(0.5'')resistance welded at every intersection.
Horizontal Wire:4mm diameter at 12.7mm centres.
Vertical Wire :4mm diameter at 76.2mm centres.
Presentation:Overtapped 75mm minimum at each post for securing with slotted clamp bars and M8 diameter bolts.
Weld Strength:
-75% of the minimum tensile strength of the wire.
-Tensile range 540-690N/M2
Application
play ground, prison, airport, power system, shipping port, bedlam.
This product has good anti-aging, resistant corrosion character. It has a beautiful appearance. When use it as a protect fence, it also make our place more beautiful.
This product has the advantage of high security, high anti-climb etc .It is widely used in the prison, airport, military base and other need high security protection places.
SCREW:
358 mesh fence specifications introduce:
Master View 358 |
2.1m |
2.4m |
3.0m |
Panel height |
2134mm |
2438mm |
2997mm |
Panel width |
2515mm |
2515mm |
2515mm |
Mesh size |
12.7 x 76.2mm |
12.7 x 76.2mm |
12.7 x 76.2mm |
Horizontal wire |
4mm |
4mm |
4mm |
Vertical wire |
4mm |
4mm |
4mm |
Panel weight |
50kg |
57kg |
70kg |
Posts |
60 x 90 x 4 mm |
60 x 90 x 4 mm |
80 x 80 x 4 mm |
Post length |
2.8m |
3.1m |
4.0m |
Clamp bar |
40 x 6 m slotted |
40 x 6 m slotted |
40 x 6 m slotted |
Fixings |
8 security nuts |
||
No. of fixings |
8 |
9 |
|
CONTACT:
