Temporary Fence Panels_ Chain Link

Specifications

Temporary Fence Panels_ Chain Link
Size:560x240x130mm
Weight:1kg
Use:temporary Fence Feet

                                                                                   Brief  instroducion





               Compay Type:Manufacturer                           Head office:Anping County,China



               Factory size:70,000sq.Meter                            nearest port:Tianjin,260km away



               Sales Amount:US $30,000,000 per year       lead time:20 days



              Main  Export Market:Austrilia,Europe,Japan,USA,South American,etc.



              Main products:Security fence,Barrier fence,Temporary fence,wire mesh fence,T-post and ect.





                                                     Certification







1.Plastic Temporary Fence Feet

Width: 220mm

Height: 150mm

Length: 600mm

Net weight: 1.5kg

Hole size:32mm, 38mm, 42mm and 48mm









2.Temporary fence clamps

All our galvanised clamps are compatible and interchangeable with all our products, including:

• Temp fence panels
• Construction fencing
• Temporary Pool safety fence
• Stays with temporary fence feet

Our clamps are also deigned to be compatible with the majority of other industry standard panels. We have the capacity to supply all Australian industries needing secure clamps, including:

• Event management
• Resources
• Construction
• Demolition
• Temp fence hire industry
• Residential Building
• Government











3.Australian standars 2.1m×2.4m,hot-dipped temporary fencing



Temporary Fencing Panel Size- 2100mm (H) x 2400mm (L)



2.1 x 2.4m fence panel
4mm wire guage
32mm OD frame
60x150mm mesh opening

600x220x150mm plastic feet

Hot dip galvanised



 Temporary fence popular size:

Popular Size
Wire Diameter	3.00-5.00mm
Mesh Opening	60 x 150mm,50 x 100mm,75x100mm, 75x75mm, 50x50mm & 100 x 300mm
H x W (mm)	2100x2400, 1800x2400, 1800x2500, 2100x2900, 2100x3300
Frame(mm)	25 OD, 32 OD, 38 OD,42 OD, 48 OD
Special size is available















4.Hot-dipped galvanized temporary fence clamps

Center distance-75mm,80mm,90mm,.100mm



5. Temporary Fence Stays



High quality Temporary Fence Stays used to support the temporary fence in high wind areas.
Hot Dipped Galvanised to Australian Standard - 42 Microns.
Specially designed for extra strength so fence stands up in very high winds.
Each Stay requires 3 Clamps and 3 Plastic Feet.











6.Different types of  temporary fence:



1) Welded Mesh Panel Temporary Fence





Popular Size
Wire Diameter	3.00-5.00mm
Mesh Opening	50 x 100mm,75x75mm, 75x100mm, 60 x 150mm & 100 x 300mm etc.
H x W (mm)	2100x2400, 1800x2400, 1800x2500, 2100x2900, 2100x3300 etc
Frame & Middle pipe	25mm, 32mm, 42mm, 48mm
Special size is available









2)Chain Link Mesh Panel Temporary Fence



Popular Size
Wire Diameter	3.00-5.00mm
Mesh Opening	60 x 150mm,50 x 100mm,75x100mm, 75x75mm, 50x50mm & 100 x 300mm
H x W (mm)	2100x2400, 1800x2400, 1800x2500, 2100x2900, 2100x3300
Frame(mm)	25 OD, 32 OD, 38 OD,42 OD, 48 OD
Special size is available











Temporary fence packing:



in bulk or in high quality pallet.
