Specifications
Charcoal powder extruding machine1.High quality and efficiency
2.Long service life
3.Low consumption
4 CE & ISO certificate
Energy-saving and long service life Charcoal powder extruding machine/charcoal powder making machine
Introduction of Charcoal powder extruding machine
This machine is a kind of briquette machines which can press the powder of coal, charcoal, carbon black
and other materials into rods which has certain intensity, the shape of rods can be round, six prismatic,
square and so on
Working principle of Charcoal powder extruding machine
1.The motor transmits power to transmission through the V-belt.
2.At the same time, the transmission output shaft transmits power to propeller through the floating coupling
3.The thruster of propeller push the materials forward through forming to produce the high-pressure sticks
Raw material and requirement of Charcoal powder extruding machine
1 coal powder
2 charcoal powder of all kinds of biomass,such as Waste material of the sawdust, wood shavings,
wood, branches, rice husk, peanut shell, bagasse, wine residue, cotton stalk, corn stalk, wheat straw,
rice straw
Features of Charcoal powder extruding machine
Thoroughly with the process of charcoal can overcome mechanism charcoal large investment, high costs,key components easily damaged . and so on . And the technology to produce charcoal product quality is stable,more product variety , In addition to the ordinary synthetic barbecue charcoal, heating charcoal, also have theburning charcoal, charcoal used in industry; The product quality and capacity is increasing; It has becomes thedevelopment trend of the future
Advantages of Charcoal powder extruding machine
1 |
First carbonization then molding , make the existing five procedure reduced to two. |
2 |
To raise the service life of wearing parts from 40 hours to 4000 hours |
3 |
Electricity costs by 60% |
4 |
production increase to 2-3 times |
5 |
Carbon powder molding machine costs fell 200 yuan per ton |
6 |
Operation difficulty is greatly reduced |
Specification
Two kinds of Raw materials:
-- Biomass Charcoal powder of all kinds of biomass,such as waste material of the sawdust, wood shavings, wood, branches, rice husk, peanut shell, bagasse, wine residue, cotton stalk, corn stalk, wheat straw, rice straw
Type |
Capacity (t-h) |
Power (kw) |
Rotate speed (rpm) |
Dimension |
KNMB-140 |
400-600 |
7.5-11 |
46-60 |
2210*1370*1440 |
KNMB-180 |
600-800 |
18.5-22 |
38-50 |
2210*1370*1440 |
--Coal powder
Type |
Capacity (t-h) |
Power (kw) |
Diameter (mm) |
Rotate speed (rpm) |
Spiral impeller diameter (mm) |
Screw quantity
|
Dimension |
KNMB-140 |
1.5-2 |
7.5-11 |
&20-30 |
60 |
&120 |
5 |
2210*1370*1440 |
KNMB-180 |
2-4 |
18.5-22 |
&10-80 |
60 |
&160 |
5 |
2210*1370*1440 |
KNMB-300 |
5-8 |
55-75 |
&18-30 |
132 |
&270 |
4 |
4080*1030 *960 |
Size of coal powder(<3mm ) moisture of coal powder(12 - 14%) | |||||||
Charcoal production line
Machine pictures :
Mould:
Finished product
Certification
