Specifications
coal briquette ball press machine1.high strength and output
2.good toughness
3 good wear-resisting performance
4 CE & ISO
Hot sale in Africa coal briquette ball press machine,coal ball presssing machine with CE and ISO
Introduction of ball press machine :
Coal ball press machine adopts briquetting twice for forming the powder into briquettes. It can press variety of materials, such as charcoal and coal powder, coal dust, coal mud, coke powder, coking coal, iron powder, iron ore concentrates, chromate ore concentrates, mgo powder, copper powder, chrome ore powder, lead zinc ore, steel slag, aluminum ash, Si-Mn mineral powder, bauxite refractory, limestone, plastic, kaolin, gypsum, nonferrous metal powder, refractory matter, ceramic lilter sand, cryolite powder and others
Features of ball press machine :
1 | The roller is made by hard materials with good wear resistance and long life time |
2 | The service life of wearing parts is up to 4000 hours |
3 | The machines electricity coal reduce by 60% |
4 | The machine is easy to operate and maintain |
5 | The molding materials are energy saving, easy to transport |
6 | The final products are smokeless, non-toxic, none peculiar |
7 | he end outlet shape of products can be all shapes |
Working principle of ball press machine :
1 | This charcoal ball press machine can press charcoal powder, charcoal dust, coal powder, etc into round ball, oval ball or pillow-shaped charcoal |
2 | This series of ball press machine will pass the power on to the two pressure roller through the reducer. The two sides and roll rotation, in both the rotating roll. |
3 | Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger.When the material to the two rollers rotating line contact point, the pressure of materials has reached the pe |
Specification of of ball press machine
Model | Roller Diameter | Power | Capacity |
TL-T290 | 288mm | 4kw | 2-4ton/h |
TL-T360 | 360mm | 7.5kw | 3-6ton/h |
TL-T400 | 400mm | 11-15kw | 4-10ton/h |
TL-T450 | 450mm | 15-18.5kw | 5-12ton/h |
TL-T500 | 500mm | 18.5-30kw | 10-20ton/h |
TL-T650 | 650mm | 30-55kw | 18-25ton/h |
TL-T750 | 750mm | 55-90kw | 15-30ton/h |
TL-T850 | 850mm | 90-110kw | 25-50ton/h |
TL-T1000 | 1000mm | 90-130kw | 50-80ton/h |
Machine pictures of of ball press machine
Other shapes finished production
Our certification
After sales service
1 Equipment (in normal use) within the warranty period, has warranty services. The whole machine warranty is 12 months, expect the wearing parts.
2 To the problem of customers' complaint about quality, immediately reaction, the marketing services personnel in 8 hours to the scene, in the province within 24 hours, 48 hours for domestic and foreign countries within 72 hours.
Contact information
Company name | Zhengzhou Known Imp.&Exp.Co.,Ltd |
Name | Laura |
knownmachine(at) | |
Tel/Fax | 86+371-53706735/86153736 |
Skype: | Laura Known |
