Hydraulic spraying machine for green landscaping

Specifications

Hydraulic spraying machine for green
Double mixing system
Elliptical tank
Superior diesel engine
No-loadiing starting

       Hydraulic spraying machine for green landscaping

Product name: hydraulic seeding machine

1,Double mixing system
2,Elliptical tank
3,Superior diesel engine
4,No-loading starting



Application of  hydraulic seeding  machine :

 (1)Hydraulic Spraying seeds Machine is the fastest, the most economical and the simplest way of establishing vegetation on bare soil surfaces to stabilize soil and prevent soil erosion.

(2)This technology involves the use of hydraulic machines in planting permanent vegetation for dust control, slope protection, grassing or stolonizing, re-vegetation and erosion prevention.

 Features of  hydraulic seeding machine :

 1.KN- HYP hydraulic spraying machine has two powerful drivers, high-performance dedicated pumps, and high ability for material delivering, best applied to the conditions like stable soil slope above 45 degree, high-filled embankment slope and man-made soil slope.

 2. Beautiful appearance, compact structure, affordable for the majority of users.

 3. with good integral mobility and complete supporting accessories. Be powered with electric-start diesel engine; be easy and convenient to operate. This machine is equipped with “Longmen” crane and this design avoids the movement of crane which sometimes will be very hard to do, can be extreme useful in the conditions moving crane is not very convenient, like farming field, slope.

 4. Safe and convenient operation. The machine is equipped with full-featured operation palette, skip-proof operation platform which has removable, 80cm-high, closed fence to guarantee the safety for console operator, spraying gun operator, as well as other staff members.

 5. Two mixing models, blades mixing and circular spray, are powerful enough to ensure the spraying mixture in the planting process is in fully suspended and fully mixed state, evenly emitting the mixture of raw materials at one time.

6. Strong power, lift distance can be reached more than 45m, and equipped with two types of spraying guns: vertical and pipe, which extend the maximum  operation scope from 200m to 300m; fan-shaped spray nozzle or mist spraying is more suitable for close-distance planting to meet various requirements

7. This machine has wide usage, not only can be applied in spraying planting for rice, grass, tress, flowers, seeds and other crops, but also in irrigation, fertilize, pesticide spraying and other daily care, soil improvement work.



Technical parameters of  hydraulic seeding  machine



Item	KN-HYP-2	KN-HYP-3	KN-HYP-5	KN-HYP-8
Volume	2m3	3m3	5m3	8m3
Mixing pump power			13.2 kw	13.2 kw
Output power	20kw	20kw	20kw	20kw
Spray distance	45m	45m	50m	55m
Spraying space/tank	1400m2	2100m2	3500m2	5600m2
Weight	1000kg	1600kg	2300kg	2500kg
Overall dimension	2.85×1.4×1.5m	3.00×1.5×2.1m	3.55×1.8×2.1m	4.65×1.8×2.1m





Contact details
Company name	Zhengzhou Known Imp. & Exp. Co., Ltd.
Website	http://zzknown.preview.china.cn
Email	nancy(at)
Contact person	Nancy
Tel:	86-371-53706735
Fax	86-371- 86153736











If you have any problems,feel free contact us. Hope to do business with you.
