low price 146L/min capacity water cooled screw chiller for sale
Introduction of water cooled screw chiller
Water cooled industrial water chiller (air cooled water chiller) using advanced production technology, superior quality, compact structure, beautiful appearance. The products can be widely used in plastics, electroplating, electronic manufacturing , pharmaceutical chemicals, food processing, laser, ultrasonic cool, printing and other industries, can accurately control the demand for modern industrial mechanized production of temperature, thus greatly improving the production efficiency and product quality.
Features of water cooled screw chiller
| 1 | brand compressors, low noise and power saving, More durable; |
| 2 | Adopt shell and tube condenser, cooling effect is good and stable performance; |
| 3 | Evaporator stainless steel water tank, built-in automatic water device; |
| 4 | Adopt imported pumps, stainless steel pump for customers to choose from, to prevent secondary pollution; |
| 5 | Microcomputer digital temperature controller, integrated operation, simple and practical, high control precision; |
| 6 | Using box structure, CNC punch press precision machining, electrostatic power paint, elegant appearance, easy to move; |
| 7 | Chiller Unit equipped with reverse phase lack protection, motor overload protection, high and low voltage protection, temperature protection and other security protection device, made the system more stable and secure. Small size, light weight, and compact structure. |
Technical parameter of water cooled screw chiller
Water cooled chiller
| model | KN-12WCD | KN-50WCD | KN-20WOD | KN-80WOD | KN-3FCST |
| cooling capacity | 36000w | 150000w | 60000 | 240000 | 7500 |
| compressor motor | 9.6kw | 41kw | 16.5 | 65.6 | 2.4 |
| cooling water flow | 146L/min | 580L/min | 190 | 880 | |
| frozen water flow | 104L/min | 430L/min | 172 | 690 | 21.6 |
| pump motor | 2HP | 7HP | 3 | 10 | |
| water tank capacity | 160L | 800L | |||
| weight | 400kg | 1100kg | 460 | 950 | 85 |
| dimension | 1300*700*1200mm | 2300*1000*1600mm | 2000*750*1200mm |
2500*750*1500mm | 900*520*800mm |
| refrigerant | R22 | ||||
| power supply | 3~380v/50hz | ||||
throttle device |
capillary tube/expansion valve | expansion valve | capillary tube/expansion valve | ||
| conderser | shell and tube condenser |
shell and tube conderser | fin tube type air cooled condenser | ||
| evaporator | stainless steel water tank cooper coil evaporator | shell and tube evaporator | PVC shell titanium tube evaporator | ||
Air-cooled chiller
| model | KN-1FCS | KN-5FCS | KN-40FCD | KN-12FCDK |
| cooling capacity | 2500w | 12500w | 100000w | 30000w |
| compressor motor | 0.8kw | 4.6kw | 32kw | 9.6kw |
| chilled water flow | 7.2L/min | 36L/min | 288L/min | 860L/min |
| pump motor | 0.5HP | 0.5HP | 5HP | |
| water tank capacity | 20L | 50L | 500L | |
| weight | 73kg | 195kg | 1050kg | 550kg |
| dimension | 850*520*900mm | 1200*680*1100mm | 2600*1000*1800mm | 1600*750*1500mm |
| refrigerant | R22 | |||
| power supply | 220V/50HZ | 3~380V/50HZ | ||
| throttle device | capillary tube/expansion valve | |||
| conderser | fin tube type air cooled condenser | |||
| evaporator | stainless steel water tank cooper coil evaporator | |||
Specification of water cooled screw chiller
| 1 | Applied imported high grade compressor and water pump, which are safe and tranquil, electricity-saving and endurance; |
| 2 | The chiller is deployed with Italy temperature controller, it can control the temperature between +3°C and 35°C exactly; |
| 3 | The designs of chiller and radiator are unique, so the heat exchange efficiency is very high; |
| 4 | The chiller is designed to be with current over-load protector, high voltage and low voltage construction and electric time-delay safeguard, when malfunction happened, it could alarm and show the cause of the problem in time; |
| 5 | It has stainless steel temperature-holder box, it is very convenience purify; |
| 6 | It is designed to be with anti-phase & lack-phase protector and anti-icy protector; |
| 7 | The temperature of ultralow chiller can be below -15°C; |
| 8 | This series chiller can customize base on the requirement of acid resistant & basicity-resistant. |
Detailed pictures of water cooled screw chiller
Advantage of water cooled screw chiller
| 1 | World famous scroll compressor |
| 2 | Adopt stainless stell water tank. |
| 3 | We have own processing department of red cooper piper and professional welding technician team for weld, completely eradicate any concurrency problems of weld break. |
| 4 | Cooling capacity:9-142.2KW |
| 5 | Support kinds of refrigerants,R22/R407C/R410A |
| 6 | We would like to production non-standard unit accoridng to client requirement. |
| 7 | Designed with imported compressor and water pump for ; |
| 8 | High-efficiency evaporator and condenser realizing rapid thermal transfer; |
| 9 | Double-compressor design to save energy and power; |
| 10 | Microcomputer touch-type control, accurate temperature control and simple operation. |
1).Pre-sale service of water cooled screw chiller
ZhengZhou Known Imp. & Exp. Co,. Ltd have one special engineer team for design, we can make the special solution according to your working need, such as customize cooling capacity, special material for ship use, seawater, corrosive, food industry, juice and wine process and etc. Just tell us:
A. What's your water composition? or industry
B. What's your temperature range?
C. What's your chilled water flow need?
D. What's the working ambient?
E. What voltage do you need?
F. What’s the cooling capacity do you need?
1. Differing Refrigerants:R22, R407, R134a can be supplied on request
2. Special voltages: 115V 220V~240V 50 Hz or 60 Hz (Single and Three Phase) are available
Then we can choose the right chiller for you.
2).Service of water cooled screw chiller
A.12 Months warranty.
B.All extra parts for the machine can be purchased with agent price from LingTong.
C.Trade manager online to support.
D.Professional technical team and sales person give you regarding troubleshooting procedures
via Internet and Phone any time when needed.
E. Free and Professional Training at our Factory under the relaxed condition.
Contact information
| company name | ZhengZhou Known Imp. & Exp. Co., Ltd |
| contact person | Nancy Dong |
| website | www.zzknown.en.china.cn |
| nancy(at) | |
| trade manager | cn1001181060 |
| tel | 86-371-53706735 |
