Introduction of flat die feed pellet making machine
Flat die feed pellet making machine,also known as a pellet press,is a type of mill or machine press used to create pellets from powdered material.Pellet mills are unlike grinding mills,in that they combine small materials into a larger,homogeneous mass,rather than break large materials into smaller pieces.
Technical parameters of DY series ring die feed pellet making machine
Model |
Capacity (kg.h) |
Power (kw) |
Diameter of Pellet(mm) |
Weight (T) |
Dimension (mm) |
DY 560 |
1000-1500 |
90 |
4-12 |
6.1 |
2600*1300*2310 |
DY 720 |
1500-2500 |
160 |
4-12 |
7.3 |
2910*1300*2410 |
DY 850 |
2000-3000 |
220 |
4-12 |
15 |
3500*1700*2900 |
DY 920 |
3000-4500 |
315 |
4-12 |
18.5 |
3900*1780*3500 |
DY 1050 |
4500-6000 |
315 |
4-12 |
22 |
4200*1850*3600 |
The parts of flat die feed pellet making machine
1. The gear of gear box uses high quality alloy steel with nitrogen case hardening dispose and grinder accurately and particularly; it has steady transmission, low noise, big bearing capacity, low rising rate in temperature and long life.
2. The main shaft is allocated with heavy load Thrust Bearing which can bear strong axial force, and has long use life.
3. Use big diameter roller to produce in higher capacity, higher pelletizing rate, uniformity and higher strength pellets.
4. Making wear-resisting process on the roller and flat die, and both sides of flat can be used to extend the its life.
5. All bearings use sealed structure to prevent entering dust so as to change the work environment of bearings and extend the use life of bearings.
6. The diameter of pellets from 6-12mm, which can be chosen by users freely.
The raw materials of flat die feed pellet making machine
Flat die feed pellet making machine is mainly used for making animal feed pellets. Corn, bean pulp, straw, grass, rice husk, alfalfa, wheat stalk,
ect. Applicable industry: aquiculture, poultry feed making plant, stock farm, poultry farm, ect.
Final Product of flat die feed pellet making machine
