Small Palm Oil Expeller Machine Line

Small palm oil expeller machine line

  The palm oil is the world's second largest edible vegetable oil, only ranking after soybean oil. At present, Malaysia and Indonesia is two largest palm oil producing countries in the world. Besides, there are many palm oil processing plants in Africa, such as Nigeria, Ethiopia, Congo, Ivory Coast etc.
Our company is professional in manufacturing   palm oil expeller machine for years. At present, we research and design a new technology of palm oil processing equipment , based on our rich experience in palm oil mill.


The following is detail introduction of our new technology-  palm oil expeller machine
Work flow of new technology  palm oil expeller machine
1. Fresh palm fruit bunch in  palm oil press machine : FFB means fresh palm fruit bunch. Palm oil fruit can be harvested all the year round. After cutting from palm trees, fresh palm fruit bunch must be processed within 2days. Or the acid value will be high and affect the final palm oil quality.

2. Threshing section of   palm oil expeller machine :
Threshing section is used to separate palm fruit seeds and the empty palm fruit bunch.

 3. No steam sterilizing section of new technology palm oil expeller machine :
 This section is used to sterilize palm fruit, the difference between our new palm oil machines and traditional way is: No Steam, No cages; No sewage (No waste water);

4. Crushing section of new technology  palm oil expeller machine :
This section is mainly to crush the palm fruit, keep palm kernel the oil unbroken, and the crude palm oil is extracted easily and effectively. The palm kernel will be transported to nut polishing system.

5. Palm fruit pressing section of   palm oil expeller machine :
To extract the crude palm oil from the palm fruit; Low oil residual in palm cake. High quality cake, which can be made to animal feed.

6. Filter section of   palm oil expeller machine :
The filter is used to remove the impurities in the crude red palm oil.

 7. Crude red palm oil-CPO

8. Refinery and fractionation section

The advantages and disadvantanges of palm oil expeller machine :

Advantages of palm oil expeller machine :
  A: No steam sterilizing, less consumption, save energy;
  B: No sewage, no waste water treatment; Less space, less cost;
  C: Empty bunches or kernel to burn. Fully use of all materials during production.
  D: Palm Cake has low moisture content, can be directly used to process animal feed.
  E: Whole palm oil mill takes smaller place than traditional method;
  F: Generate electricity by the system itself, solve electricity problem.

Disadvantages of palm oil expeller machine :
Whole system has limits of capacity: 3tph-5tph -10tph-20tph-30tph;
 This system is mainly proper for small and medium palm oil mill;

  Comparison of traditional and new technology of palm oil expeller machine

1. Work flow of new technology palm oil expeller machine
 FFB-Threshing-No steam sterilizing-Crushing-Pressing-Filtering-Crude Palm oil
                ↓
Empty palm bunches-boiler

2. Brief introduction of traditional palm oil expeller machine
Raw materials storage section----Steam Sterilizing section----Threshing section----Pressing section----Clarification section----Crude oil storage and transportation section----Fiber separation section----Kernel recovery section----Sewage treatment section

The traditional technology is proper for bigger capacity palm oil milling machine , like 30tph, 60tph, 80tph and above. Unlike traditional process, we have designed a new technology specially for smaller capacity palm oil milling machine , like 3tph-5tph-10tph-20tph.

 Various seeds oil content:

the specification of crude palm oil

 the specification of refined palm oil

If you are interested in  palm oil expeller machine , your prompt reply is highly appreciated.
