Specifications
1.Mustard oil refinery machine2.Edible oil refinery machine
3.40 years experience
4.Provide turnkey project
5.CE&ISO&BV
Crude Mustard oil refinery machine with ISO CE certificate
Introduction of crude Mustard seed oil refining machine
The process of Mustard seed oil refining is to refine the crude Mustardseed oil, to remove gossypol, protein, phospholipid, grume, moisture and other impurities, in order to reach the purchase of food and storage.
According to different raw materials, the process of Mustard oil refining includes mechanical refining method, chemical refining method and physical refining process refining process.
Main process of the refining:
1. Crude Mustard oil degumming process,
2. Crude Mustard oil deacidification/neutralization process
3. Crude Mustard oil decoloring process
4. Crude Mustard oil deodorization/distillation(deodorising unit) process
5. Crude palm/corn/rice bran oil dewaxing(fractionation) process
Main parts of Mustard oil refining machine
What's the application of Mustard oil refining plant?
The refining machine can process different kinds of raw crude Mustard oil.
Like Crude Mustardseed oil refining, crude sunflower oil refining, crude peanut(groundnut) oil refining, crude rapeseed oil refinery, CPO refining, crude rice bran oil refining, crude corn oil refining and other crude edible oil refinery.
What's the process Mustard oil refining plant:
(1)Pump crude edible oil into refining tank and heat with conduction oil, and the temperature will reach about 70°C-80°C after one hour.
Add acid or alkali to separate according to the acid value. After one hour's processing and 4-6hours deposit, then convey soap stock to storage tank.
(2)Pump refined oil into decoloring tank. When it is up to 90-110°C after one hour's heating, add clay into tank for 20min's processing. Then separate clay and oil with filter.
(3)Put decolorizing oil into deodorization tank with vacuum pump. Heat and process with steam for odor removal. After filtering, you will get final oil product.
What's the functions of Mustard oil refining process?
(1) Refining section: used to P-acid de-gumming, alkali refining de-acid and water rinsing.
(2) Decoloring section: used to remove off pigments, bleaching oils and grease dehydrate, make the oil lucency
(3) Deodorizing section: to remove off the odor components in oil, let the oil have a good smell
(4) Dewax section: used to remove off the wax in the oil, in order to get the high quality oil.
What's the final Mustard oil product's specification?
Item |
Quality index |
||||
1st grade |
2nd grade |
3rd grade |
4th grade |
||
Moisture & Volatile matter/ % Moisture & Volatile matter/ % ≤ |
0.05 |
0.05 |
0.10 |
0.20 |
|
Impurities / % ≤ |
0.05 |
0.05 |
0.05 |
0.05 |
|
Acid value(KOH)(mg/g) ≤ |
0.20 |
0.30 |
1.0 |
1.0 |
|
Peroxide value/(mmol/kg) ≤ |
5.0 |
5.0 |
7.5 |
7.5 |
|
Test tempeature (280°C) |
_ |
_ |
No educt,Lovibond Tintometer: Yellow value not changed,red value increasing<0.4 |
Trace of educt,Lovibond Tintometer: Yellow value not changed,red value increasing<0.4 blue value<0.5 |
|
Saponified matter content / % ≤ |
_ |
_ |
0.03 |
0.03 |
|
Smoke point / °C ≥ |
215 |
205 |
_ |
_ |
|
Freezing test (0°C Storing 5.5hrs) |
Transparent |
_ |
_ |
_ |
|
Solvent residue/(mg/kg) ≤ |
Solvent extraction crude oil |
None |
None |
50 |
50 |
Press crude oil |
None |
None |
None |
None |
|
Doing Group have the whole line of oilseeds pressing, solvent extraction line and refinery line.
The processing capacity is as below:
10-2000 T/D oilseeds prepress line and pretreatment line
20-2000 T/D Automatic and complete rotocel extractor and loop type extractor
2-1000 T/D Animal fat, oil fat, used Mustard oil/PAD/PFAD to biodiesel production line
Doing Group has more than 40 years experience on oil machinery, turnkey project service will be provided to customers.
Doing Group have installed hundreds of plant all over the world, our responsible engineers, advanced tech and experienced installation worker will make your choice better and better.
Packaging and shipping at port
Shipping of oil refining plant
Doing Group provide turnkey project service for the customer from all over the world, can provide equipment manufacturing, worker training, factory debugging and commissioning.
If you are interested in our service and products, please feel free to contact me.
Regards
Abby
Crude Mustard oil refinery machine with ISO CE certificate
