latest technology mini grain dryer|mini dryer grain|seed grain dryer China making machines
Mini Grain Dryer is used for drying materials with humidity or granularity in the industries Of mineral dressing building material, metallurgy and chemical, It can be used for drying Many kinds of materials such as: limestone slag, coal powder, stag, and clay stone, and It is made from rotary body, lifting blade, driving device, supporting device and sealing Ring.
Working principles:
1. Bucket elevator transports the wet material into the feeder.
2. Feeder sends the wet material into the rotary drier silo.
3. Feeder cover keeps the materials not leaking and maintains the temperature of pulp.
4. Drum dryer rotates slowly by motor power to heat material evenly.
5. Lifting plate: through the rotating of transfer cylinder and the mixing of the lifting plate, the materials are heated fully and the water is evaporated.
6. Dust blower and then dust collector cyclone: the dust generated by the mixing of the dried material in the warehouse was discharged out through dust fan and dust collector cyclone, this drying way is environmental.
8. Discharging cover maintains the temperature in the silo, discharge the dry materials orderly.
9. Rotary discharging feeder: The dry materials are transported on the belt conveyor through rotary discharging feeder.
10. Belt conveyor: the dried materials are transported into product stock by the belt conveyor or directly bulked.
Raw materials:
Technical Parameters of Rotary drying machine:
Model | Obliquity | Rotation speed | Feeding temperature | power | capacity
| weight |
DY-600*6000 | 3%-5% | 3-8(r/min) | <=700 | 3kw | 0.5-1.5(t/h) | 2.9t |
DY-800*8000 | 3%-5% | 3-8(r/min) | <=700 | 4kw | 0.8-2.0(t/h) | 3.5t |
All the goods exported are packed in wooden case or carton with export standard except naked package when necessary.We have our own professional shipping company which could deliver the goods to every corners in the world with safety and speed, and also can supply the services of solving the problems occured during the transaction, such as customs cleaning.
1.Pre-sale services:
Act as a good adviser and assistant of clients; enable them to get rich and generous returns on their investment
(1) Select equipment model;
(2) Design and manufacture products according to clients’ special requirement;
(3) Train technical personnel for clients.
2.Services during the sale:
Respect clients; devote ourselves to improving the total value of clients.
(1)Pre-check and accept products ahead of delivery;
(2)help clients to draft solving plans.
3. After-sale services:
Provide considerate services to minimize clients’ worries.
(1) Assist clients to prepare for the first construction scheme;
(2) Install and debug the equipment;
(3) Train the first-line operators on site;
(4) Examine the equipment regularly;
(5)Take initiative to eliminate the troubles rapidly at site;
(6) Distribute the guarantee fittings door-to-door;
(7)provide perfect service;
(8)Provide technical exchanging;
(9)Provide maintenance for big items.
Your prompt inquiry is highly appreciated. I will reply you asap when I get your inquiry.
Henan Doing Mechanical Equipment Co,Ltd. Is a professional manufacturer of rotary drying machine, We have been in rotary drying machine manufactuering industry for 40 years. With rich experiences, our engineer team helps customers design different rotary drying machines with different capacities .
Any more question about mini grain dryer, please feel free to contact us at any time.
