Specifications
oil presser machine:1. high oil rate
2. good quality of the final oil
3. different output
Introduction:
All kinds of models of screw automatic
| oil filter |
made by us are of many good advantages: material selection is exquisite, reasonable design, beautiful shape, reliable quality, simple operation, less land occupation, labor saving, power saving, high yield, and oil quality is good, and so on. All technical indexes are leading in the same trade of the state-owned oil press. And the model of 6YZ-80 and 6YZ-100 are the new type products reformed by our factory engineers, which are the advanced equipment in the oilseeds processing machinery recently.
Good advantages:
simple structure, easy to use, adaptable, high oil rate, energy-saving, and low noise. This series of machinery can be widely used to more than 20 kinds of easy and difficult plant oilseeds, such as peanuts, soybeans, rapeseed, cottonseed, sesame, olives, sunflowers, coconut, cocoa, seeds and so on. During pressing, it can be entirely squeezed one-time(except for some individual varieties).
Working principle:
The process of pressing oil is filtered by vacuum, so the residue of the oil is rather little and ensures the hygiene degree of pure oil. Our company also produces the equipment of drum-express hydraulic oil, six to eight kilograms of raw materials only need six to ten minutes from raw materials into the machine to oil, which has been received good comments by customers. Additionally, we produce granule selected machines, automatic speculation seed machine, automatic oil filter, and electric control machines, etc. to equip with a variety of oil processing machines available for you to choose from.
Technical parameter:
|
model Technical parameter |
6YZ-80(1685) |
6YZ-100(1688) |
6YZ-150(D1698) |
|
|
Diameter of worm section |
80mm |
100mm |
150mm |
|
Rotary speed of worm section |
50-60rounds/min |
40rounds/min |
45 rounds/min |
|
Diameter of inscribed circle of press boring |
82mm |
102mm |
152mm |
|
|
Equipped force |
Main frame |
Y132-6-5.5KW |
Y132M6-7.5KW |
Y160L-4 -15KW |
Vacuum pump |
Y80-4-0.55KW |
Y801-4-1.1KW |
Y905-4- 1.1KW |
|
heater |
3KW |
3.5KW |
6KW |
|
Capacity (kg/h) |
80-150kg/h |
150-250kg/h |
230-500kg/h |
|
Weight (kg) |
780kg |
1100kg |
1800kg |
|
Overall dimension(L*W*H) |
1800*1300*1750 |
1980*1450*1800 |
2300*1700*1800 |
|
If you have any interest in our products, please feel free to contact me, and I will give you a good price and best quality. My mobile is 8615039094214
Thanks and best regards!
