Specifications
wood powder pulverizing machine powder grinderhigh-efficiency energy-saving
CE,ISO9001:2000
wood powder pulverizing machine
Wood powder machine
new type wood powder machine
The wood powder machine is a kind of new superfine wood powder machine which is developed under the inovation of our R&D team with three grinding principles. It’s efficient and energy-saving. This kind of new wood powder machine is dedicated to various difficult grinding of light materials, fiber materials, brittle materials, and ductile materials.
Features of wood powder machine
1 Its self-suction feeding replaces traditional grinder which feeds directly that wood powder machine can be destroyed if a piece of metal is put into inlet carelessly. Thus the new wood powder machine is promised to be safe all the time.
2 The processing technology is fine enough and can inject water to cool itself.
3 It includes a new material that is able to abstract heat and noise.
4 The appearance is beautiful and it’s firm that it can be used for a long time.
5 High output. Its efficiency is more than 50% high than other traditional wood powder machines.
The scope of application:
Wood powder machine is applicable for hundreds of difficult grinding like wood powder, sawdust, bamboo powder, rice husk, wheat bran, herbs, bark, eaves, corn cob, straw, shrimp, seaweed, dehydrated vegetables, spices, paper, circuit boards, plastics, chemical raw materials, graphite, activated carbon, cellulose, tea, hair, plant root, stem, leaf, flower, fruit, and all kinds of edible fungus. It’s the ideal grinder in chemicals, building materials, medicine, health, breeding, food, mosquito coils and others.
Sub-item |
Water-cooling 500 type |
Water-cooling 700 type |
Water-cooling 800 type |
Water-cooling 900 type |
Rotary speed of principal machine (r/min) |
2900 |
2900 |
2900 |
2900 |
Motor of principal machine (Kw) |
18.5 |
22-30 |
22-30 |
45 |
Motor of blower fan (Kw) |
4 |
4 |
4 |
4 |
Output(Kg) |
60-300 |
100-500 |
120-500 |
150-600 |
Feeding size(mm) |
<25-30mm |
<30-35mm |
<30-40mm |
<30-40mm |
Output size(mesh) |
10-325 |
10-325 |
10-325 |
10-325 |
Length, width and height of land occupied (m) |
5×2×4.5 |
5×2.5×4.5 |
5×2.6×4.5 |
5×2.9×4.5 |
Weight(ton) |
1.1 |
2.2 |
2.6 |
3.8 |
