Specifications
Raw materialWood branches wood chips rice straw,wheat straw ,corn straw, grass river reeds,palm husk,soybeans husk coffee husk
Sawdust machine
Application:
Sawdust machine also named wood crushing machine and wood crusher, it can crush wood logs,wood block and wood waste into sawdust and granular with different fineness.
wood crusher is suitable for milling raw material like tree branch, tree trimmings, cotton stalk, corn stalk, wheat straw etc with size less than 50mmdiameter. After milled, the output size can reach to 3-5mm diameter after milled , which is suitable for further pelletizing and briquetting.
Operating Principle:
The wood crusher produced by our company is a kind of newly-developed wood crushing equipment for raw wood, which is an innovation on the basis of traditional crusher-making theories both home and abroad. It is composed of machine body, knife chipping part, chips re-crushing part and sieving part, etc. It combines both chipping and crushing in one machine, can make sawdust in one passage, no need to use wood chipper for pre-processing of wood logs.
Advantages:
To ensure security, the feed inlet of this machine adopts self-suction design to avoid serious damage to operators.
Low investment and energy consumption,
High output
High quality finished products
Easy to operate and maintain
Model of machine |
BX800 |
BX600 |
BX400 |
Diameter of cutter head(mm) |
800 |
600 |
400 |
Quantity/block of blade |
4-6 |
4 |
4 |
Length of blade(mm) |
230 |
200 |
125 |
Dimension of feeding opening(mm) |
250×230 |
250×200 |
144×150 |
Rotary speed of main shaft(r/min) |
2100 |
2600 |
2600 |
Equipped force (kw) |
30 |
22-30 |
15-22 |
Output(kg/h) |
1000-1500 |
800-900 |
600-700 |
