Disk Type Wood Slicer and Wood Chipper

Disk Type Wood Slicer and Wood Chipper photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Place of Origin:
Henan, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Lianyungang
Delivery Detail:
Delivery time depends on order quantity.
Condition New
CNC or Not Normal
Place of Origin Henan, China
Brand Name DAFU
Model Number 2L*640

Specifications

Disc wood chippers can cut log and small-diameter log with less than 200mm diameter.

Disk type wood slicer and wood chipperDisc wood chippers introduction:
1. The chipper supplied by us are special wood chipping machine to produce high quality wood. This machine is widely applied to papermaking, shaving board and MDF area or wood produce base.
2. The chipper highly structured, reasonable structure, easy installation, operation and maintainence, high production capacity. When cutting the raw wood, the wood chips is high quality and also the chips length can regulate freely in the defined range.
3. The chipper is mainly composed of four parts such as principal machine, coupling, bottom frame and motor, etc, in which the principal machine of chipping machine is composed of cutter head, upper and lower covers, feed inlet and outlet, etc.
4. The chipper can be made by user specific requirement.
Specifications of Disk Timber Chipping Machine
Mobel of machine 2L×640 2L×1000
Diameter of cutter head(mm) 640 1000
Rotary speed of cutter head(r/min) 970 740
Quantity(sheet) of fly cutter 6 6
Length of wood chip,thickness(mm) 15-35 2-3 15-35 3-7
Mode of feeding Declination Declination
Dimension of feeding opening(mm) 150×140 250×250
Productive Capacity (t/h) 3-5 5-8
Power of electric motor(kw) 37 75
Maximum diameter of cutting wood(mm) 100 200
Mode of discharging Up Up
Weight of complete machine (kg) 1192 3375
External dimension (length×width×height) 2002×1175×1360 2820×1838×1892
Notice: Any change of Timber Chipping Machine technical data shall not be advised additionally.
