Specifications
home use oil press machine : material selection is exquisite, reasonable design, beautiful shapeThe process of pressing oil is filtered by vacuum, so the residue of the oil is rather little and ensures
the hygiene degree of pure oil. Our company also produces the equipment of drum-express hydraulic oil, six to eight kilograms of raw materials only need six to ten minutes from raw
materials into the machine to oil, which has been received good comments by customers. Additionally,
we produce granule selected machines, automatic speculation seed machine, automatic oil filter, and
electric control machines, etc. to equip with a variety of oil processing machines available for you to choose
from.
These small scale screw type oil presses are advanced oil seed presses, characterized by their high oil output rate with good quality, simple design, easy to use and continuous operation. Our screw oil press can use for various raw material, such as peanut, beans, rape and cotton seeds, sesame, olive, sunflower, coconut, grass seed etc.
There are many good advantages of home use oil press machine: simple structure, easy to use, adaptable, high oil rate, energy-saving, and low noise. This series of machinery can be w idely used to more than 20 kinds of easy and difficult plant oilseeds, such as peanuts, soybeans, rapeseed, cottonseed, sesame, olives, sunflowers, coconut, cocoa, seeds and so on. During pressing, it can be entirely squeezed one-time(except for some individual varieties).
Technical parameter of home use oil press machine :
|
model Technical parameter |
6YZ-80(1685) |
6YZ-100(1688) |
6YZ-150(d1698) |
|
|
Diameter of worm section |
80mm |
100mm |
150mm |
|
Rotary speed of worm section |
50-60rounds/min |
40rounds/min |
45 rounds/min |
|
Diameter of inscribed circle of press boring |
82mm |
102mm |
152mm |
|
|
Equipped force |
Main frame |
Y132-6-5.5KW |
Y132M6-7.5KW |
Y160L-4 -15KW |
Vacuum pump |
Y80-4-0.55KW |
Y801-4-1.1KW |
Y905-4- 1.1KW |
|
heater |
3KW |
3.5KW |
6KW |
|
Capacity (kg/h) |
80-150kg/h |
150-250kg/h |
230-500kg/h |
|
Weight (kg) |
780kg |
1100kg |
1800kg |
|
Overall dimension(L*W*H) |
1800*1300*1750 |
1980*1450*1800 |
2300*1700*1800 |
|
Performance of home use oil press machine:
Oil material |
Oil press rate (%) |
Thickness of the material slag |
Residual oil ratio (%) |
sesame |
42-55 |
1.0-1.5 |
≤7 |
peanut |
40-50 |
0.8 - 2 |
≤8 |
rapeseed |
28-43 |
1.0-1.5 |
≤8 |
Sunflower seeds |
30-40 |
1.2-1.5 |
≤8 |
Soy bean |
10-16 |
0.8-1.5 |
≤7 |
