Automatic Ring Die Pellet Mill
1.Machine introduction:
This Ring Die Alfalfa Feed Pellet Mill is mainly used for making wood pellets , the pellets used for industry, boiler factories , the machine can be produce φ6.0,φ8.0,φ10.0,φ12.0 pellets. The raw materials can be: sawdust, rice husk, cotton stalk, cottonseed skins, weeds, crop stalks and other plant wastes, especially low-bonding and unformed materials.
It adopts imported SKF or NSK bearings, the motor brand is Siemens or china famous Wannan brand.
Driven by gear .more strong than by belt, and the capacity 10% higher than by belt.
It is also matched the safty equipment , once overload , the safty pin will crack, to protecting the machine lifetime.
2.Technical parameters:
Model |
Power of main motor(kw) |
Capacity (t/h) |
Power of feeding motor(kw) |
Power of conditioner(kw) |
Diameter of ring die(mm) |
Size of final pellets(mm) |
HTO-SZLH320 |
37 |
0.2--0.4 |
1.1 |
2.2 |
320 |
φ6.0,φ8.0, φ10.0,φ12.0 |
HTO-SZLH350 |
45/55 |
0.4--0.6 |
1.1 |
2.2 |
350 |
|
HTO-SZLH400 |
75/90 |
0.5--1.2 |
1.5 |
2.2 |
400 |
|
HTO-SZLH420 |
90/110 |
0.8--1.4 |
1.5 |
5.5 |
420 |
|
HTO-SZLH508 |
132/160 |
1.5--2.0 |
1.5 |
5.5 |
508 |
3.Contact information:
If you need further information, please contact us freely, we will do our best to cooperate with you.
