Rubber Grinder With Easy Operation
1. Machine introduction of rubber grinder:
a. The machine adopts water cooling and air cooling design, suitable for all kinds of natural rubber, synthetic rubber after crushing grinding powder; Can be below 80 degrees grinding all kinds of rubber into rubber powder fineness is 30-200 purpose, production of up to 350-60 kg/h mill design, the use of special material hardness can reach more than HRA93.
b. The advent of the recycle of waste rubber will play an important role in the processing of powder supply rubber products factory after processing can be made into the tyres, rubber shoes, gaskets, seals and other rubber products, can also be directly with asphalt waterproof coiled material and elastic floor tile, paved with rolling sole and direct sports track and runway, highway, etc.
c. It is made up of crusher, mill by the automatic feeding, automatic transmission, automatic milling, automatic screen to send, automatic dust removal parts, such as one-stop production. Overcome the low production and labor intensity big, can't deal with tire and continuous production can not, can produce all kinds of waste rubber dragon (such as bicycle, motorcycle, tractor, car inner tube, outer tube, soles, seal, gasket, rubber factory Angle materials, conveyor belt, etc.) and using high pressure under the action of grinding and shear the principle of combining grinding temperature can be controlled effectively. Ensure that the quality of the powder.
2. Technical parameters of rubber grinder:
Model |
HTO-FSJ50 |
HTO-FSJ80 |
HTO-FSJ100 |
|
380V/50Hz |
380V/50Hz |
380V/50Hz |
22kw |
30kw |
45kw |
|
Blower power |
380V/50Hz |
380V/50Hz |
380V/50HzS |
4kw |
4kw |
14kw |
|
Total power |
28kw |
36kw |
51kw |
Cutter diameter |
350mm |
450mm |
600mm |
Feed diameter |
≤6mm |
≤6mm |
≤6mm |
Discharging pin-size |
15-100 |
15-100 |
15-100 |
Produce |
50-150kg/h |
80-450kg/h |
100-750kg/h |
Dimensions |
2300*100*3300mm |
35001200*4000mm |
4500*1350*4500mm |
3. Photos of rubber grinder:
4. Contact information:
If you need further information, please contact us freely, we will do our best to cooperate with you.
