Commercial Plastic Injection Molding Machine
1. Machine introduction:
The Full-auto Blow Molding Machine is human and machine interface that is easily operated. There are single mould base, double moulds base, single mould head to six mould heads, single layer to six layers, multi-layer with liquid level line, mold inside logo, air-pressing water setting, automatic scraps collecting system, the daily output (24 hours) reaches approximately 12,000 to 60,000; it can produce 0.5-2.5L plastic hollow products.
2. Technical parameters:
Item |
Unit |
Parameter |
Model |
|
HTO-40 |
Raw Material |
- |
PE/PP/PVC/EVA... |
Station |
|
2 |
Diameter of screw |
mm |
55 |
L/D of screw |
- |
24:1 |
Extrusion Power |
KW |
7.5 |
Plasticizing Capacity |
kg |
40-50kg/h |
Mould length |
mm |
300 |
Max. Clamping Force |
KN |
50 |
Molding Head |
piece |
2 |
Pressure of air source |
Mpa |
0.6 |
Air consumption |
m3/min |
0.4 |
Water Consumption |
m3/h |
1.2 |
Weight |
T |
1.2 |
Dimention |
m |
2.5*1*1.7 |
3.Contact information
If you need further information, please contact us freely, we will do our best to cooperate with you.
