Stainless Steel Automatic Vacuum Desiccator
1.Machine introduction:
Automatic Vacuum Desiccator is widely used in pharmaceutical, chemical, foodstuff and electronic industry, and it is well known that vacuum drying is put raw materials into the environment of vacuum for heating and drying, if use vacuum pump to draw air and humidity out, the dry speed will be faster.
2.Working principle:
To heat and dry raw materials under the state of vacuum is called vacuum drying. It use vacuum to pump air and humidity out. Making the work-room on the vacuum state. The drying rate increases greatly and energy is saved. Note: if use condenser, the solvent in raw materials can be recovered. If use SK series water ring vacuum pump or ZSWJ series hydraulic inject vacuum pump sets, condenser can not be used and the investment could be saved.
3.Technical parameters:
Description/Specification |
HTO-YZG600 |
HTO-YZG1000 |
HTO-YZG1400 |
HTO-FZG15 |
internal size of drying cabinet(mm) |
φ600×976 |
φ1000×1527 |
φ1400×2054 |
1500×1400×1220 |
external size of drying cabinet(mm) |
1153×810×1020 |
1693×1190×1500 |
2386×1657×1920 |
1513×1924×2060 |
layers of drying holder |
4 |
6 |
8 |
8 |
layer distance(mm) |
81 |
102 |
102 |
122 |
size of drying pallet(mm) |
310×600×45 |
460×640×45 |
460×640×45 |
460×640×45 |
number of drying pallet(pieces) |
4 |
12 |
32 |
32 |
pressure inside the drying pipe(MPa) |
≤0.784 |
≤0.784 |
≤0.784 |
≤0.784 |
temperature of the drying holder(°C) |
≤150 |
≤150 |
≤150 |
≤150 |
unload vacuum inside (MPa) |
-0.09∼0.096 |
|||
model and power of the vacuum pump when condenser is not equipped(kw) |
SK-1.5 4kw |
SK-3 5.5kw |
Sk-6 7.5kw |
Sk-3 7.5kw |
weight of drying cabinet(kg) |
250 |
800 |
1000 |
2100 |
4.Contact information:
If you need further information, please contact us freely, we will do our best to cooperate with you.
