Specifications
1.Widely usefessional design
3.Raw material wide adaptability
4.With CE
5.Advanced technology
Helical surface disc slicer 800 disc chipper machine
Introduction:
Disc chipper by number of plate on the knife is divided into: general chipper (4-6 knife) and multiple blade chipper (8-6 knife) two kinds. These two chipper feeding way and oblique mouth mouth feed feed peace (or horizontal feeding) two kinds. Long logs of shavings, generally adopt the feeding mouth, short log and slab shavings can be used oblique mouth feed, can also use flat mouth to feed.
Main processing materials:
slab, wood, cotton, all kinds of crop straw, etc.
Application:
Helical surface disc chipper, cutting diameter 200 mm the following logs, trails and branches, is suitable for pulp mill, forest field, factory, wood factory, etc.
Main data:
model |
800 |
feeding inlet size(mm) |
250x250 |
speed of roller(r/min) |
740 |
roller diatemer (mm) |
800 |
length of final chips(mm) |
2-50 |
capacity(t) |
3-5 |
power(kw) |
30-37 |
weight(kg) |
1680 |
dimesion(mm) |
2008×1400×1492 |
