Manufacturer supply commerical pineapple juicer machine
Usage and application of the fruit and vegetable juicer
The fruit and vegetable pulping machine is an ideal machine for making jam, fruit juice, vegetable juice, suitable for a variety of fresh fruit and vegetables in pulping separation. such as: orange flesh, grapes, kiwi, mulberry, waxberry, peach (to nuclear) and so on,it can change them into jamjuice,it can also pulping green vegetables , tomatoes, peppers, celery. the vegetables bar isolated, is an important equipment for food processing .The machine can separate fruit juice and tomato skin and seed.
Structure of the fruit and vegetable juicer
This juicer are consist of :former supporting bar,feed hopper,spiral,filter mesh, juicer holding device,back supporting bar,slag notch etc.
Working Principle of the fruit and vegetable juicer
By the former bearing, a feed hopper, spiral, filter net, gravy, support, slag notch parts, screw spindle bearing in rolling bearing, the right end is supported on the wheel bearing, a triangular belt wheel drive motor to work through the spiral.
Model |
LZ-0.5 |
LZ-1.5 |
LZ-2.5 |
Capacity |
500Kg/hr |
1500Kg/hr |
2500Kg/hr
|
Diameter of the screw (mm) |
Φ87.5mm |
Φ175mm |
Φ250mm
|
Diameter of the filter mesh |
0.6mm |
0.6mm |
0.6mm
|
Power (kw) |
1.5Kw |
4Kw |
11Kw |
Spindle speed (rpm/min) |
400rpm |
400rpm |
400rpm |
Weight (kgs) |
100Kg |
240Kg |
480Kg |
Size (mm) |
1100×265×920 |
1560×450×1340 |
1980×680×1620 |
For further details,please click on the following video:
Packing details: exported standard wooden box
Delivery details: within 7-15 days after receiving your deposit
If you want to get more information, plesae do not hesitate to contact us!
