Ginger Fruit Extractor Machine / Sugarcane Peeling Machine / Fruit Juicer
Working principle of the juicer:
The main component of this equipment is a spiral slag outlet direction along the bottom diameter increase gradually and the pitch decreases, when the material is the spiral propulsion, because the spiral cavity volume reduction, squeeze the material.aw materials are added to the feed hopper, compression screw propulsion, Sheng juice is squeezed juice through the filter into the bottomof the annular gap is formed between the tapered portion, and waste through the spiral and regulating the discharge, mobile pressure head along the axial adjustable pore size. For the clockwise (equipment from the slag notch to the feed hopper end rotates the handwheel shaft
bearing seat, adjustable head to the left, and vice versa, voids and narrow gap larger.)
|
Model
|
LZ-0.5 |
LZ-1.5 |
LZ-2.5 |
Capacity |
500Kg/hr |
1500Kg/hr |
2500Kg/hr
|
Diameter of the screw (mm) |
Φ87.5mm |
Φ175mm |
Φ250mm
|
Diameter of the filter mesh |
0.6mm |
0.6mm |
0.6mm
|
Power (kw) |
1.5Kw |
4Kw |
11Kw |
Spindle speed (rpm/min) |
400rpm |
400rpm |
400rpm |
Weight (kgs) |
100Kg |
240Kg |
480Kg |
Size (mm) |
1100×265×920 |
1560×450×1340 |
1980×680×1620 |
For machine working video,please click this website link.thanks.
/play/u/3056331757/p/1/e/1/t/1/47916294.swf
If you have any questions for this production,you can contact me at any time,Thanks.
*******************************************************************************************************
