Specifications
1. Optimal Design of the boiler2.Best auxiliary configuration system
3.Safefy
4.Easy examine and repair
Hot sale horizontal normal pressure hot water boiler for hotel
Product Features:
Optimal Design of the boiler
Adopted the wet back structure, layout low heating chamber and symmetrical arrangement to ensure the safety and
reliability of boiler operation.
Enhanced the original heat transfer, so that the gas flow under the flocculation station to reduce the volume of boiler
and consumables.
Reasonable gas flow rate, with the best computer program control, so that
the life time and operation costs can achieve the best.
Cancellation traditional small smoke chamber structure, eliminating the original structure of the situation caused by
the tube plate cracking while increasing the volume of water that can accommodate large load fluctuation.
Best auxiliary configuration system
Adopt configure class combustion equipment, so that the combustion is complete while the low pollution emission
with low noise, less than a ringelmann smoke, good environmental performance.
With hightech boiler controller so that the boiler can be automatic controlled in the whole process. The operation is
very simple, just set
the water temperature, the whole system operates automatically without staff guards.
Safefy
Protect by multilevel security chain such as low water level, high temperature ignition and failure lockout. With
antifreeze fault alarm protect function.
Atmospheric boiler set large pores, which has overpressure protection features to ensure the safe operation.
Easy examine and repair The design idea of split charging, module combination, no blind sports maintenance for all
parts such as fire ports, fire door, heat preservation system and package control etc., which makes maintenance be
easily.
Range of application:
For the heating of factories, residences and large hotels and general hospitals and hot water for life.
|
parameter Model |
CMNS0.70 |
CMNS1.05 |
CMNS1.40 |
CMNS2.10 |
CMNS2.80 |
|||||||||
The rated heating power |
mw |
0.70 |
1.05 |
1.40 |
2.10 |
2.80 |
||||||||
Heat efficiency |
% |
89.0 |
89.0 |
90.5 |
91.0 |
91.0 |
||||||||
Heating area |
sq.m |
19.84 |
28.5 |
37.4 |
55.2 |
62.4 |
||||||||
Nominal working pressure |
Mpa |
0 |
||||||||||||
Rated supply water temperature |
°C |
85/60 |
||||||||||||
Fuel |
Light Oil, natural gas, liquefied petroleum gas |
|||||||||||||
Fuel Consumption |
Light oil |
Kg/h |
66.1 |
99.1 |
130.0 |
183.9 |
258.5 |
|||||||
Natural gas |
Nsq.m/h |
79.3 |
118.9 |
156.0 |
232.7 |
310.2 |
||||||||
Liquefied petroleum gas |
Nsq.m/h |
30.6 |
45.9 |
60.2 |
89.9 |
119.8 |
||||||||
Pressure |
Natural gas |
mmH2o |
200 |
600 |
600 |
1000 |
1400 |
|||||||
Liquefied petroleum gas |
mmH2o |
200 |
600 |
600 |
1000 |
1400 |
||||||||
Voltage |
V/HZ |
380/50 |
||||||||||||
Power |
KW |
1.1 |
1.5 |
2.2 |
5.5 |
7.5 |
||||||||
Gas pipe |
DN1(mm) |
100 |
100 |
125 |
150 |
150 |
||||||||
Water pipe |
DN2(mm) |
80 |
100 |
100 |
125 |
150 |
||||||||
Blow-off pipe |
DN3(mm) |
40 |
40 |
40 |
40 |
50 |
||||||||
Diameter of chimney |
Φ1(mm) |
250 |
300 |
300 |
400 |
400 |
||||||||
Condensate drain outlet |
A |
25 |
||||||||||||
Fuel input interface |
Light oil |
A |
10 |
10 |
10 |
15 |
20 |
|||||||
