Specifications
1. high automation2. safe&efficient
nvenient
4. low consumption
2013 Hot selling horizontal automatic biomass boilers
Features:
Control system: microcomputer control system, temperature setting, cycle control and fault alarm function,
simple and easy to use.
High automation we use advanced rotary screw drive automatic feed device to feedthe fuel automatically only
need to fill the storage hopper one time to satisfy 12days need. We use automatic ignition of the burner of
electric for the ignition so that it can reduce the fireman labor's work to a great extent,
makes the use of boiler more humane.
Safe&efficient biomass boiler is a hot water boiler that runs under normal pressure, does not require the
annual inspection, does not require a professional fireman to operate boiler uses integral insulation is not
only reduces ht heat loss, but also improves the thermal efficiency environmental protection type heat
equipment.
It can be widely used in garment manufacturing, good processing industries, hotel services, petrochemicals,
schools, hospitals, and enterprises, especially for the users in those areas have high requirement on
environmental protection and energy saving.
Technical date:
Rated heating value |
Unit |
CLHS0.035 |
CLSH0.058 |
CLHS0.08 |
CLSH0.12 |
CLHS0.18 |
CLHS0.23 |
Working pressure |
Normal pressure |
||||||
Water temp |
°C |
85/60 |
|||||
Thermal efficiency |
% |
≥90 |
|||||
Heating area |
Sq.m |
200-300 |
400-500 |
500-700 |
700-1000 |
1000-1500 |
1500-2000 |
Fan power |
Kw |
0.08 |
0.18 |
0.55 |
0.55 |
0.75 |
0.75 |
Blower |
Kw |
0.1 |
0.1 |
0.1 |
0.1 |
0.1 |
0.1 |
Heater band |
Kw |
4 |
4 |
4 |
4 |
4 |
4 |
Feeder-conveyor |
Kw |
0.25 |
0.25 |
0.25 |
0.25 |
0.25 |
0.25 |
Diameter of chimney |
Mm |
140 |
140 |
140 |
140 |
140 |
140 |
Length |
Mm |
1300 |
2170 |
2170 |
2230 |
2620 |
1550 |
Width |
Mm |
450 |
500 |
550 |
600 |
600 |
1300 |
Height |
Mm |
1260 |
1260 |
1370 |
1380 |
1600 |
1650 |
Weight |
Kg |
380 |
420 |
430 |
450 |
510 |
780 |
Consumption |
Kg/h |
8 |
14 |
19 |
28 |
42 |
56 |
