Industrial Oils Flexitank Container for Transportation

Industrial Oils Flexitank Container for Transportation thumbnail-1
Industrial Oils Flexitank Container for Transportation thumbnail-2
Industrial Oils Flexitank Container for Transportation thumbnail-3
Industrial Oils Flexitank Container for Transportation photo-1
Industrial Oils Flexitank Container for Transportation photo-2
Industrial Oils Flexitank Container for Transportation photo-3
US$ 170 - 230 MOQ: 10 Sets
Key Specifications
Get Latest Price
Grade:
Food
Suitable for:
20" Container
Place of Origin:
Shandong, China
Contact Supplier Request Quote Chat Now
Qingdao LET Flexitank Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Grade Food
Place of Origin Shandong, China
Brand Name LET
Model Number 18~24KL

Specifications

1.4 layers PE+1 layer PP
2.Food grade
3.3inch ball valve or butterfly valve
4.insurance

Electrical Heating Pad







Size: 1.150x5.500m



1. Input AC voltage :220V , 230V , 50-60 Hz AC .



2. Output power 1 5 00 0 W , 1 8 0 0 0W , 2X6000W .



3. Output control temperature: 50 , 55 , 60 °C



4. Output protection temperature: 80 °C .



5.Size:1088X1088mm,1000X1300mm,2X1200mmX5500mm for 20’ container



6. Aluminum foil surface: 0.05 mm .



7. Intermediate medium using:0.05mm Aluminum foil or 0.5mm ivory board.



8. The reverse side USES heat preservation carpet or 0.05mm Aluminum foil.





Steam Heating Pad



Material: EPDM+ caoutchouc



Working pressure:< 0.2 Mpa
Temperature range : < 220°C
Heat source : Steam



Layout dimension :  5.7 m(length) X 2.3 m(width)



Weight :   30kg



LET Leading Technologies





a). The valves are fixed on flanges by designing, which has efficiently solved connecting leakage problem between valves and flexitanks.



 Our valves are installed with safety devices for preventing liquid from blocking valves and reducing the residual liquid quantity when unloading.



 With the unique design of protective layer, valves can efficiently avoid container pollution from smashed liquid



b). Special anti-shake design enhances the stability and safety of liquid transportation



LET flexitank types





a)Top Loading & top Discharging(TLTD)

b)Bottom Loading &bottom Discharging  (BLBD)

c)Top Loading & Bottom Discharging (TLBD)



Application



 LET Flexitank accessories



a) Steel Bar (L: 2410mm)—5pcs/ one set
b) Corrugated Paper (L: 3000mm)—1 roll/one set
c) Bulkhead (W*H:2330mm*1480mm)—1 pc/one set

d) Butterfly valve(3''/4'')

e) Foam strip (L: 1300mm)-1 pc/one set

e) Heating Pad (For choice)

f) Air Release Valve (For choice)



industrial oils flexitank container for transportationindustrial oils flexitank container for transportationindustrial oils flexitank container for transportation
