Catalyst Support Monolith Ceramic Honeycomb

Catalyst Support Monolith Ceramic Honeycomb thumbnail-1
Catalyst Support Monolith Ceramic Honeycomb photo-1
Negotiable MOQ: 1 Cubic Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Type:
Ceramic Parts
Application:
Industrial Ceramic
Contact Supplier Request Quote Chat Now
Pingxiang Kangyu New Power Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangxi, China
Type Ceramic Parts
Application Industrial Ceramic
Material Alumina Ceramic

Specifications

1.used on vehicle
2.better air flow
3.less backpressure
4. high thermal shock resistance,high strength

Honeycomb ceramic is a new developed porous industrial ceramic. As heat storage body, it has the properties of corrosion resistances, large specific surface area, small heat resistance, good thermal conductivity and excellant thermal-shock resistance performance, realize quickly exchanging heat and reducing energy, widely used in the industrial field. The honeycomb ceramic as the heat exchange media is the key part for heat storaging HTAC ( High Temperature Air Combustion) technology. It is the best choice for RTO, heat exchanger and other environmental protection and energy saving products.

                                        Chemical Composition:

Chemical Composition Alumina Porcelain Cordierite Mullite unit
SiO2 36.7~38.15 46~48 27~28 %
Al2O3 50.75~52.5 34~37 70~71 %
MgO 3.8~4.4 7.00~7.50 ~~~ %
Fe2O3 0.70~0.90 0.70~0.90 0.50~0.70 %
CaO,K2O,Na2O 3.00~3.30 2.50~2.90 0.80~1.20 %
TiO.BaO 2.4~3.6 0.30~0.40 ~~~ %

                                   Specification:

Type Dimensions(mm) Specifications English Units Metric Units Remarks
MJ– 1 150*150*300 25*25 channels     Also available with any length between 50mm-300mm
Width of Channels 0.193 in 4.9±0.1 mm
Wall thickness 0.043 in 1.1±0.1 mm
Specific surface area 164.6 ft2/ ft3 540 m2/m3
Free cross section 67 % 67 %
MJ– 2 150*150*300 59*59 channels     Also available with any length between 50mm-300mm
Width of Channels 0.118 in 3.0±0.1 mm
Wall thickness 0.027 in 0.7±0.1 mm
Specific surface area 251.5 ft2/ ft3 825 m2/m3
Free cross section 65 % 65 %
MJ– 3 150*150*300 50*50 channels     Also available with any length between 50mm-300mm
Width of Channels 0.079 in 2.0±0.1 mm
Wall thickness 0.020 in 0.5±0.1 mm
Specific surface area 375.0 ft2/ ft3 1230 m2/m3
Free cross section 63 % 63 %
MJ– 4 150*150*300 25*25 channels     Also available with any length between 50mm-300mm
Width of Channels 0.091 in 2.3±0.1 mm
Wall thickness 0.027 in 0.7±0.1 mm
Specific surface area 306.4 ft2/ ft3 1005 m2/m3
Free cross section 57 % 57 %
MJ– 5 150*150*300 20*20 channels     Also available with any length between 50mm-300mm
Width of Channels 0.244 in 6.2±0.1 mm
Wall thickness 0.043 in 1.1±0.1 mm
Specific surface area 164.6 ft2/ ft3 540 m2/m3
Free cross section 67 % 67 %
MJ– 6 150*150*300 35*35 channels     Also available with any length between 50mm-300mm
Width of Channels 0.142 in 3.6±0.1 mm
Wall thickness 0.020 in 0.5±0.1 mm
Specific surface area 245.4 ft2/ ft3 805 m2/m3
Free cross section 79 % 79 %
MJ– 7 150*150*300 43*43 channels     Also available with any length between 50mm-300mm
Width of Channels 0.114 in 2.9±0.1 mm
Wall thickness 0.020 in 0.5±0.1 mm
Specific surface area 304.9 ft2/ ft3 1000 m2/m3
Free cross section 72 % 72 %
