Ceramic Intalox Saddle

Ceramic Intalox Saddle thumbnail-1
Ceramic Intalox Saddle photo-1
Negotiable MOQ: 1 Cubic Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Type:
Ceramic Rings
Application:
Industrial Ceramic
Contact Supplier Request Quote Chat Now
Pingxiang Kangyu New Power Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo shanghai shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangxi, China
Type Ceramic Rings
Application Industrial Ceramic
Material Alumina Ceramic
Model Number Ceramic Intalox Saddle packing
Brand Name KAGNYU

Ceramic Intalox SaddleKANGYU Intalox Saddles



Introduction:



Intalox saddle has excellent acid resistance and heat resistance. It can resist to corrosion of various inorganic acids, organic acids and organic solvents except hydrofluoric acid, and can be used in high or low temperature conditions. Consequently the application range is very wide. It can be used in the drying columns, absorbing columns, cooling towers, scrubbing towers and actifier columns in chemical industry, metallurgy industry, coal gas industry, oxygen producing industry, etc.



Chemical composition

SiO2

Al2O3

Fe2O3

CaO

K2O+Na2O

>70%

23-30%

<1%

<1-2%

<2-4%



Physical properties

Index

Value

Specific gravity(g/cm3)

2.25-2.35

Water absorption(%)

<0.5

Acid-resisting strength, %Wt. Loss (ASTMc279)

<4

Firing temperature(Degree C)

1280-1320

Softening point(Degree C)

>1400

Density(kg/m3)

2350

Technical data

Spec. (inch)

Spec. (mm)

Approx. weight (kg/m3)

Surface area (m²/m³)

Free volume (%)

Packing factor (l/ft)

1/2

12

720

623

71.7

200

3/4

19

688

334

73

130

1

25

688

253

73

85

1.5

38

640

164

75

50

2

50

577

115

77.4

37

3

76

623

92

75.5

24



Advantage
These saddles are made from chemical porcelain and have excellent resistance to acids except in the case of hydrofluoric acid.
Moisture absorption must less than half a percent.
The porcelains specific gravity is 2.3-2.4g/cm3 and an average heat capacity (between 20 and 500 of 0.22 cal/g.)
XINTAO ceramic saddles softening point is 1400 min. And they show good thermal shock resistance during repeated cycling between 20 and 820 .

Thermal shock test for Intalox Saddles
For example shipping the saddles over 80 M3:
1) Randomly pick 100-200 pieces of ceramic saddles for RTOs from the batch or shipment
2) For each sample selected, heat it up to 820 and maintain them at this temperature for 30 minutes.
3) Drop the hot pieces into cold 20 water
4) Repeat steps 2 & 3 for10 times on each and every piece in the sample lot.
5) Examine the pieces and count the percent that show clear signs of breakage and/or cracking. Our standard is less than seven (7%) percent.
