Ceramic Cross-Partition RingSize:50mm 50mm 100mm 120mm 150mm
ISO9001:2008
Ceramic Cross-Partition Ring
Professional manufacturer for ceramic cross-partition ring, size available: Dia.50mm, 80mm, 100mm, 120mm, 150mm etc.
Ceramic Cross Partition Ring has excellent acid resistance and heat resistance. It can resist to corrosion of various inorganic acids,
organic acids and organic solvents except hydrofluoric acid, and can be used in high or low temperature conditions.
Consequently the application range is very wide. The packing can be used in the drying columns, absorbing columns, cooling towers,
scrubbing towers and actifier columns in chemical industry, metallurgy industry, coal gas industry, oxygen producing industry, etc.
Technical Data
Spec. |
D*H*T(mm) |
Surface area (m²/m³) |
Free volume (%) |
Number per m³ |
Bulk density (Kg/m³) |
Dry Packing Factor (m-1) |
Ø 50 |
50*40*50*5 |
145 |
50 |
6400 |
600 |
565 |
Ø 80 |
80*64*80*8 |
120 |
56 |
1950 |
820 |
356 |
Ø100 |
100*80*100*10 |
110 |
53 |
1000 |
850 |
252 |
Ø120 |
120*96*120*12 |
75 |
55 |
370 |
860 |
146 |
Ø150 |
150*120*150*15 |
60 |
58 |
295 |
980 |
101 |
