Forestry Machinery
Fog Generator Applications Above and Beyond Dust Suppression
In addition to controlling job site dust, our line of products have additional applications from odor control to crop fertilization to cooling ambient temperatures of sports practice fields by up to 20 degrees as well as mimicking various rain and wind conditions.
Detailed Application:
1. Dedusting cooling for environmental protection industry, mining, quarry, coal yard, docks, steelworks, and other dust relatively large construction site .
2. Fruit-bearing forest, nursery garden, farmland, lawn and so on. Spray pesticides or liquid fertilizer.
3. Sterilization and antiepidemic for housing estate, Quarantine area, livestock-raising area, school, hospital, enterprise and public institution, station, shipside and other public areas.
4. Deinsectization and sterilization for small areas in all kinds of environment outdoors.
5. Also used for soil treatment before sowing, weed killing in seeding stage and pest control. Suitable for all kinds of crop, such as soybean, wheat, corn, cotton, potato and so on. Also suitable for herbal medicine, pasture, flowers and plants and so on.
Fog Generator Specification:
Model |
WF200 |
WF150 |
Dimension |
2000*1750*3100mm |
2000*1750*3000mm |
Match power |
250kw diesel generator set |
110kw diesel generator set |
Spray fog flow |
80-320L/min |
60-240L/min |
Horizontal range |
175-200m |
130-150m |
Vertical range |
75-85m |
65-75m |
Blower power |
110kw |
55kw |
Working pressure |
1.0-2.0Mpa |
1.0-2.0Mpa |
Overhead downward Angle |
-10°-40° |
-10°-40° |
Rotation angle |
350°up and down adjustable |
350°up and down adjustable |
Our Forestry Machinery Features:
1. Strong capability, long range, wide coverage, high efficiency and spray speed.
2. For dedusting in the yard where is easy to cause the dust, spray mist particles are so small that it can form a wet mist when contact with the float dust, quickly restrain dust drop.
3. Supporting power is flexible. you can either use three-phase 380V mains, or generator set.
4. It can be fixed in high platform, can also be installed in the transport vehicle with matching generator power.
5. Flexible, safe, reliable operation, remote control and manual control operations, simple adjustment of the horizontal rotating spray angle.
6. Less water consumption compared to other dust suppression spray equipment (gun, sprinklers), and the mist covering area on dust is much larger than other dedusting machines.
Our other spray system models:
Model |
WF80 |
WF60 |
Dimension |
1550*1200*2200mm |
1250*1000*2000mm |
Match power |
24kw diesel generator set |
20kw diesel generator set |
Spray fog flow |
30-120L/min |
20-80L/min |
Horizontal range |
60-70m |
50-60m |
Vertical range |
36-45m |
30-38m |
Blower power |
30kw |
7.5kw |
Working pressure |
1.0-2.0Mpa |
1.0-2.0Mpa |
Overhead downward Angle |
-10°-40° |
-10°-40° |
Rotation angle |
350°up and down adjustable |
350°up and down adjustable |
Operation reality images
We supply various kinds of sprayer:
Water Pump:
Certificate of our sprayer:
Welcome to cooperate and develop with us!
