Automatic heating With 2 years warrantee wood briquette machine
Brief introduction:
This type used wood briquette press machine is a new generation of energy-saving products, researched and developed by our researcher newly. It is mainly for the renewable or recycled organic material's densification and molding. it can produce the solid stick charcoal from the different raw material via the high temperature and high pressure procedure.The whole production line can help you make the material stick charcoal directly,Save energy and high efficiency.
" used wood briquette press machine " features:
The finished of wood chips carbon block, small volume, more than major, burning resistance, easy to storage and transportation, the volume is only 1/30 of the original straw, with weight is 10 to 15 times of the straw, the density of 0.9 ~ 1.4 g/cm3, calorific value can be up to 3500 to 5500 calories, and between the high volatility is a solid fuel
Advantages and characteristics:
1.This machine has a reasonable structure , stable performance, equipped with forced lubrication system, high efficiency, low energy consumption, good forming effect, simple operation, easy maintenance.
2.The unique mold structure for machining of various water crops straw: (1) the good adaptability to extend the raw material’s production cycle; (2) the size of material is 3 ~ 30 mm, moisture content in the range of 16% ~ 30%.
Data of used wood briquette press machine
model |
|
SDM-810 |
SDM-980 |
SDM-1000 |
power(KW) |
|
37 |
45 |
55 |
capacity(t/h) |
|
1.3—1.8 |
2—2.5 |
2.8—3 |
speed(r/min) |
|
980 |
980 |
980 |
voltage(v) |
|
380 |
380 |
380 |
model diameter(mm) |
|
810 |
980 |
1000 |
model hole number |
|
36 |
42 |
60 |
Briquette specification(mm) |
|
32*32 |
32*32 |
32*32 |
material length(mm) |
|
3—60 |
3—60 |
3—60 |
moisture of raw material(%) |
|
15—30 |
15—30 |
15—30 |
molding density(t/m3) |
|
0.8—1.4 |
0.8—1.4 |
0.8—1.4 |
particle temperature |
|
100 degrees below |
100 degrees below |
100 degrees below |
Dimension(mm) |
2700*1000*1800 |
1700*1100*1800 |
2700*1200*200 |
|
The weight(t) |
|
2.8 |
3.2 |
4.3 |
