Zhengzhou Alpha Machinery Co., Ltd.: Zhengzhou, Henan, China; Main products: Food Processing Machinery, Agriculture Machinery, Construction Machinery, Mining Machinery, Shelling&Peeling Machinery

Home > Products > Energy Machine > Coal Ball Pressing Machine Coal Ball Forming Machine

Coal Ball Pressing Machine Coal Ball Forming Machine

Name: Coal Ball Pressing Machine Coal Ball Forming Machine
Brand: ALPHA
Availability: InStock

FOB Price

US$ 2,000 - 5,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Production Capacity	4-6T/H
Motor Type	AC Motor	Power(W)	7.5KW
Place of Origin	Henan, China	Brand Name	ALPHA
Model Number	AE-CB 290	Dimension(LWH)	190018002000mm
Certification	CE ISO	Warranty	12 Months
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Coal ball pressing machine coal ball forming machine

Product Description

1. Brief introduction of coal ball pressing machine

Coal ball press machine is the equipment to press powder materials into ball shape. The design of the product is mainly used for pressing dry power into pellet material in the magnesium-making

. After many years of industrial use and improvement, compared to other similar products, the series of ball press machine have many obvious advantages, such as high pellet rate, low consumed power, compact structure, easy maintenance and debugging, etc; Thus, it is a kind of key ideal equipment for magnesium-making technology by pidgeon process.

2. Models of coal ball pressing machine

Model	AF-CB 290	AF-CB 360	AF-CB 450	AF-CB 500	AF-CB 650	Remark
Capacity(t/h)	1-3	3-5	6	8-10	15
Roller Width(mm)	200	250	250	300	330	65Mn
Roller Diameter(mm)	288	360	400	500	650
Power(KW)	5.5	7.5	11-15	22-30	45-55	According to material
Spindle Speed(rpm)	18	15	13	13	13
Reducer	ZQ350	ZQ350	ZQ400	ZQ500	ZQ750
Reducer	ZQ400	ZQ400	ZQ500	ZQ650	ZQ850
Pressure Form	Tapered Iron Constant Pressure	Tapered Iron Constant Pressure	Tapered Iron Constant Pressure	Tapered Iron Constant Pressure	Tapered Iron Constant Pressure	Optional
Pressure Form	Axle Seat Drawbar	Axle Seat Drawbar				Optional
Roller Material	65Mn	65Mn	65Mn	65Mn	65Mn	Casting	Optional
Roller Material	9Cr2Mo	9Cr2Mo	9Cr2Mo	9Cr2Mo	9Cr2Mo	Casting	Optional
Structural Type	Double Shaft Single Pressure	Double Shaft Single Pressure	Double Shaft Single Pressure	Double Shaft Single Pressure	Double Shaft Single Pressure	Optional
Structural Type	Four Shaft Double Pressure	Four Shaft Double Pressure	Four Shaft Double Pressure	Four Shaft Double Pressure	Four Shaft Double Pressure	Optional
Main Shaft	Φ95mm	Φ110mm	Φ135mm	Φ165mm	Φ200mm
Main Shaft	45#Steel	45#Steel	Forging	Forging	Forging
Ball Size	Defined by users	Defined by users	Defined by users	Defined by users	Defined by users	Commonly used 30-60mm

3. Features of coal ball pressing machine

High efficiency and reasonable price
High productivity
Easy to operate and no flying dust
Low cost but high quality and efficiency
Long service life
Environmental friendly
Easy to repair and debugging

Packaging & Shipping

1.We always use standard export packing, carton box. But for our customer, Alpha Machine give a free Wooden Package to protect your machines.

2.You can choose express, by air, by train or by sea. Always we will give our best recommend based on our experience.

3. We cooperate with China best shipping company to get best price and fast delivery.

4. You will get full feedback when your machine is on the way.
