double roller organic fertilizer granulation with competitive price
contact me
MS June
Mob:0086-13676938131
Skype:junemachine
Trademanager:cn1501660008
Introduction of Fertilizer Granulator
1.Double roller fertilizer granulator is a newly developed granulating machine in fertilizer industry.
2. It has higher granulating ratio of over 85%.
3. It uses squeezing principle to form fertilizer particles with diameters of 3.5-10mm in one time.
4. Double roller fertilizer granulator is the most popular granulating methods in no-drying (2%-5% moisture content) fertilizer process at room temperature.
5. Less cost and quick granulating,thus it can bring fertilizer investment a good economic returns.
Main Paramter of fertilizer granulator
Model |
TZ-I 1.0 |
TZ-I 2.0 |
TZ-I 3.0 |
TZ-I 4.0 |
TZ-II 1.0 |
TZ-II 2.0 |
Production(t/h) |
1~1.5 |
1.5~2.5 |
2.5~3.5 |
3.5~4.5 |
1~2 |
1.5~2.5 |
Power |
15KW |
18.5KW |
30KW |
45KW |
15KW |
18.5KW |
Pressure roller Spec |
Φ150×22O |
Φ150×30O |
Φ186×30O |
Φ300×30O |
Φ150×22O |
Φ150×30O |
Feed size |
≤ 0.5mm |
≤0.5mm |
≤ 0.5mm |
≤ 0.5mm |
≤ 0.5mm |
≤ 0.5mm |
Finished product Spec |
Φ2.5~Φ10 |
Φ2.5~Φ10 |
Φ2.5~Φ20 |
Φ2.5~Φ30 |
Φ2.5~Φ10 |
Φ2.5~Φ20 |
Raw materials of Fertilizer Granulator
1) Agricultural waste: straw, dregs of beans, cotton dregs, rice bran,etc.
2) Animal manure: mixture of poultry litter (PL) and animal waste(AW),such as, Slaughterhouse Waste, Fish Market, Urine and dung of cattle, Pigs, Sheep,C hicken, Ducks, Geese, Goat.etc.
3) Industrial waste: wine lees, vinegar residue, manioc waste, sugar scum, furfural residue etc.
4) Home scrap: food waste, bones, the roots and leaves of vegetables, etc.
5) Sludge: the sludge of the river, the sewer, etc.
Advantage of Fertilizer Granulator
1. Create higher intensity and uniform length fertilizer particles,high granulating ratio.
2. Granulating process finishes at room temperature,less investment.
3. Multifunctional.Applicable to various fertilizer particles like organic fertilizer,inorganic fertilzier,compound fertilizer and magnetic fertilizer,etc.
4. Low noise, stable granulating process,tailored fertilizer granulator and service.
5. Sturdy and reasonable structure,high quality steel materials,good economic benefits.
Working principle of fertilizer granulator
The series of roll granulation is extrusion model , its working principle is the belt and pulley driven by electric motors ,
to the driving shaft to pass through the reducer , and synchronization off then gear and the driven shaft opposite the work
Material from the hopper to join, after the roll extrusion molding , mold release , making the ball ,
and after a chain sent to the broken screen studio , under the screen and the separation of the finished pieces (the ball) tablets .
And then return the mixture of material with new material , refor granulating . With the continuous rotation of motor , the material continues to enter in order to achieve mass production .
