Incoloy 800HT Corrugated Gasket
- Tianjin/Shanghai
- T/T Money Gram Credit Card
You May Like
Product Details
| Brand Name | HT | Model Number | Incoloy 800HT Corrugated Gasket | |
| Material | Metal | Shape | Other, Corrugated Gasket/Flat Gasket/Grooved Gasket/Ring Gasket/Serrated Gask | |
| Standard or Nonstandard | Standard |
Product Description
Specifications
Incoloy 800HT Corrugated Gasket1. ASME B 16.20, API 6A
2. 1/2"-36"
Incoloy 800HT Corrugated Gasket
Ring joint gasket are suitable for high pressure and high temperature applications,available in R,RX,BX styles,R style can be in oval or octagonal cross section .
All the ring joint gaskets are manufactured by CNC machines according to ASME B16.20 standard and API 6A requirements .
Main use: petroleum processing,oil refining,electricity generated by firepower,textiles and other light industries,pharmacy,piping of natural gas,valve,RTJ flange,steam and petrol industry,petrolchemical industry,oilfield ect.
Gasket type | Gasket cross section | Ring joint gasket standard | Flange standard |
Oval |
| ASME B 16.20 API 6A | ANSI B 16.5ASME B16.47, series A |
Octagonal | ASME B 16.20 API 6A | ANSI B 16.5 ASME B16.47,seriesA | |
RX | ASME B 16.20 API 6A | API 6 B | |
BX | API 6A | API 6 BX |
Available material
Material | Maximum Hardness (BRINELL) | T(°C) |
Soft Iron | 90 | 530 |
Low Carbon Steel | 120 | 530 |
4C6% Chrome 1/2% Mol(F5) | 130 | 500 |
304 Stainless Steel | 160 | 750 |
316 Stainless Stee | 160 | 750 |
321 Stainless Stee | 160 | 750 |
347 Stainless Steel | 160 | 750 |
410 Stainless Steel | 170 | 500 |
31254 Stainless Steel | 160 | 650 |
Monel | 140 | 600 |
Inconel 825 | 160 | 1000 |
Inconel625 | 180 | 1100 |
