Garlic Root Cutting Machine(Concave Cutting)|Garlic Root Cutter

Garlic Root Cutting Machine(Concave Cutting)|Garlic Root Cutter photo-1
Garlic Root Cutting Machine(Concave Cutting)|Garlic Root Cutter photo-2
Garlic Root Cutting Machine(Concave Cutting)|Garlic Root Cutter photo-3
Garlic Root Cutting Machine(Concave Cutting)|Garlic Root Cutter photo-4
Garlic Root Cutting Machine(Concave Cutting)|Garlic Root Cutter photo-5
US$ 1,000 - 6,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
longer
Model Number:
LGQ-01
Payment & Shipping
Payment Methods:
Port of Shipment:
Qing dao port/Tianjin port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Henan, China
Brand Name longer
Model Number LGQ-01
Type Other, Garlic Processing Machine
After-sales Service Provided Engineers available to service machinery overseas

Garlic Root Cutting Machine(Concave Cutting)|Garlic Root Cutter

This machine is configurated with circular knife with high cutting speed. The blades will not produce fever and without any damage to the garlic. After cutting, the garlic root will be concave circular arc. The root will be removing

clearly and the efficiency is high.

1, Working procedure:

Put the garlic( the garlic root is on upper side) on the running conveyor belt by manual. The conveyor will send the garlic to the blades , then the blades will cut the root out quickly and completely.

2, Adjustment of cutting depth the garlic root

There is one Blades Adjuster on this machine. Before cutting, adjust the Blades Adjuster to be well according to your cutting requirement, the machine can control the cutting depth automatic during the next working procedure.

3. The size of the garlic

There are three grades of garlic.

The diameter of garlic is smaller than 40mm, we called it small size garlic. When feeding garlic, we can use small size garlic conveyor.

The diameter of garlic is between 40mm and 55mm, we call them to be Normal Size Garlic. We can use the normal size garlic conveyor to feed the garlic.

The diameter of garlic is bigger than 55mm, we call them to be Big Size Garlic. We need to use the big size garlic conveyor to feed this kind of garlic.

4,When you cut the garlic with same grade, no matter how bigger or smaller it is, the machine can recognize and cut the garlic root automatically according to their size .



Model

LGQ-01

Power

1.5kw,380V/220V

Cutter

2 pieces

Capacity

400-500kg/h

Material

Stainless Steel 304

Dimension

1200*600*1000mm

 Garlic Root Cutting Machine(Concave Cutting)|Garlic Root CutterGarlic Root Cutting Machine(Concave Cutting)|Garlic Root CutterGarlic Root Cutting Machine(Concave Cutting)|Garlic Root Cutter
