Quick Details
Condition: |
New |
Type: |
sieve |
Application: |
oil industry |
Place of Origin: |
Henan China (Mainland) |
Brand Name: |
SHULIY |
Model Number: |
SL model |
Voltage: |
380v |
Power(W): |
7.5kw |
Dimension(L*W*H): |
4500*1950*2550mm |
Packaging & Delivery
Packaging Detail: |
in container |
Delivery Detail: |
15 days after order |
Specifications
Double drum sieve
1.high quality and high separating rate
fessional for oil processing industry
Double drum sieve
Description:
This machine is commonly used to oil processing, it is for cleaning the oil seed which after crushing,
and can separate the shell and kernel.it has high cleaning rate, very easy to operate, it is the best choice for oil process industry.
Operating Principle:
Drum screen consists of motor, decelerator, rotor drive, chassis, inlet and outlet. Material feeds into the drum, is lifted up by the rotation and aerated as it falls back down. This action is repeated with each revolution along the length of the drum. The finer material passes through the screen openings
while the larger material tumbles towards its eventual exit at the rear of the drum.the screening rate:0.3% kernel rate from shell, and 12% shell rate from kenel.
Parameter:
Model |
SLDS-2-80 |
SLDS-3-80 |
Sieve plate size |
18.2 m2 |
27 m2 |
Capacity |
60-80t/day |
100-120T/day |
Motor |
7.5kw |
11kw |
Mesh diameter |
φ4-φ6(mm) |
φ4-φ6(mm) |
sieve diameter |
φ800mm |
φ800mm |
sieve length |
3600 mm |
3600 mm |
sieve speed |
12r/min |
12r/min |
Main spindle speed |
145 r/min |
145 r/min |
External dimensions |
4800×1950×2550(mm) |
5000×2700×2900(mm) |
Entire machine weight |
3200 kg |
3900kg |
Welcome to visit our factory!!!
