Slabs And Wood Waste Pellet Maker Machine
Product desription of wood waste pellet maker
1) This series machine are mainly used for pelletizing all kinds of biomass particles, such as wood sawdust, straw, rice husk and coffee husk etc.
2) The main drive adopts high precision GEAR DRIVING and the capacity is increased by 20% than belt drive.
3) Super quality IMPORTED bearing and oil seal to ensure high efficiency, stability and low noise.
4) The pelletizing chamber is equipped with air draft COOLING SYSTEM to ensure the capacity of pellets.
5) The variable-frequency and variable-speed MOTOR is adopted to ensure the quality of the pellet.
6) It’s optical of bore diameter of ring die that is made of ALLOY STEEL to ensure long life, so to save cost of replacement.
7) Advance compensatory S-SHAPE spring coupling with the structure of novel, compact, safe, low noise and fault.
8) The machine can be made to semi-automatic oil lubricating system or fully automatic oil-lubricationg system, according to your request.
Technical parameter of wood waste pellet maker
Model | Capacity | Motor power | Feeder power | Force feeder power | Ring die inner dia | Noise |
AZSMKLH350 | 0.6T/H | 55KW | 1.5KW | 0.75KW | 350mm | ≤86db(A) |
AZSMKLH420 | 1.0T/H | 90KW | 2.2KW | 1.1KW | 420mm | |
AZSMKLH508 | 1.5T/H | 110KW | 2.2KW | 1.1KW | 508mm | |
AZSMKLH558 | 1.8-2.0T/H | 132KW | 2.2KW | 1.1KW | 558mm | ≤90db(A) |
AZSMKLH678 | 3T/H | 220KW | 3.0KW | 1.5KW | 678mm | |
AZSMKLH768 | 4T/H | 315KW | 4.0KW | 2.2KW | 768mm |
Exporting items of wood waste pellet maker
We have different model of this series machine which can meet your different capacity.
| | |
| | |
Detail Show of wood waste pellet maker
Application of wood waste pellet maker
Making wood pellet for fuel and animal bedding, by all kinds of biomass particles, such as wood sawdust, straw, wood shaving, wood waste, wood chips, rice bran, coffee husk etc.
Packing for wood waste pellet maker
After inspection and send machine pictures to our clients, the machines are packed in wooden case to ensure the safety during transportation. Or load into 20GP container.
____________________________________________________________________________
Automatic Biomass Wood Pellet Production Line
1) Crushing-wood crusher
2) Drying-Drum dryer
3) Pelletizing-wood waste pellet maker
4) Cooling-Contraflow cooler
5) Packing-packing machine
Please do not hesitate to contact BELLA WU, if you need any more information or have any other questions. We will be at your service at any time.
