Apparel Machinery computerised Sticker stone making machine

Plastic film covered and carefully loaded into plywood wooden case

Specifications

Sticker stone making machine
1.Computer control ,USB interface
2. Multiple colors
3.Fast speed ,180 pcs/ min
4.Automatic

Apparel Machinery computerised Sticker stone making machine



Application of Sticker stone making machine



1)Hot fix the loose rhinestones onto different materials,such as,Cotton,Jeans,

Hemp fabric,Woolen,Synthetic Fiber,Silk,Kintwear,Leather,Velvet.

2)Hot fix the loose rhinestones onto transfer papers.



Introduction of Sticker stone making machine

 Computer touch screen control system characteristics:

1.Rtos system,fast starting speed,it only takes 3 seconds to enter into the system.

Electricity can be powered off at any time.



2.Optional operating language.(Chinese,English,French,Spanish,Portuguese,

Arabic,Russian).True color operation interface.



3.WIFI ,U disk input pattern are available.



4.To return to the starting point , to rotate , enlarge, and repeat patterns;

boundary detection,pattern edit,and simulate hot fixing operation.



5.Color change function(You can manually change the disc or change color

automatically according to a preset color sequence.)



6.The basic storage stitches is 600,000,000 needle.



7.Vacuum intelligent induction make it easy to use . Manual adjustment is

unnecessary.



Main festures of Sticker stone making machine





1.The main components adopts imported electrical components,it is reliable

 quality.

2. Infrared positioning, precisely hot fix the rhinestone's position and be very

 strong.

3.Can continuously work 24-hour, high efficiency production.

4.Best choice for the products can not resist high temperature and easy to

deformation and discoloration .





Technical parameter of Sticker stone making machine



Model	AZSDZ06-A	AZSDZ06-B	AZSDZ06-C
Voltage	220V/110V    50HZ/60HZ	220V/110V    50HZ/60HZ	220V/110V    50HZ/60HZ
Speed	150-180/MIN	150-180/MIN	150-180/MIN
Net weight	150KG	500KG	500KG
Size(L*W*H)MM	1300*990*1300	3300*1300*1300	4900*3000*1600
Working table size	450*450mm	400*500mm	600*1200mm
Welding head quantity	1 head	4 heads	4 heads
Rhinestone Disc(color)	2 pcs(2 colors)	8 pcs(2 colors)	8 pcs(2 colors)



Model	AZSDZ06-D	AZSDZ06-E
Voltage	220V/110V    50HZ/60HZ	220V/110V    50HZ/60HZ
Speed	150-180/MIN	150-180/MIN
Net weight	150KG	200KG
Size(L*W*H)MM	1300*990*1300	1300*1030*1060
Working table size	450*450mm	400*450mm
Welding head quantity	1 head	2 heads
Rhinestone Disc(color)	4 pcs(4 colors)	4 pcs(2 colors)





More photos for our Sticker stone making machine







More options for rhinestone machine



(Click the below pictures to learn more about it)





   Hand operating (Favorable price)                 Half automatic(Fast speed , labor saving)



Working effect of rhinestone transfer machine





         Before (A little dull?)                   After (So amazing!)





If you are interested in , please call me or email me .
