commercial tilting jacketed kettle/agitator kettle/steam cooking kettle with agitator
1. introduction
This machine is suitable for mixing, concentrating and decocting the material in pharmaceutical, foodstuff and chemical industry etc. It is the best choose for jam making such as the matt jam and strawberry jam making, tomato sauce making. and candy, medicine, dairy, alcohol, cake, beverage, sweetmeat.
This machine is composed of kettle ,backet ,worm wheel and worm etc. The kettle can revolve with 180 degree.. The machine is made of stainless steel SUS304,which has perfect corrsion-proof performance, and is highly endurable according to GMP requirements. Blender also can be added according customer requirements.
2. machine application
Be widely applied in food processing such as candy, medicine, dairy, alcohol, cake, sweetmeat, beverage, can, etc.
3. technical parameter
Model | ASL-50 | ASL-100 | ASL-200 | ASL-300 | ASL-400 | ASL-500 | |
Capacity | 50L | 100L | 200L | 300L | 400L | 500L | |
Material | SUS304 | SUS304 | SUS304 | SUS304 | SUS304 | SUS304 | |
Evaporating quantity(kg/h) | 30 | 40 | 65 | 75 | 100 | 150 | |
Heating area(m2) | 0.4 | 0.45 | 1.0 | 1.15 | 1.44 | 1.90 | |
Energy consumption(kg/h) | 33 | 44 | 72 | 90 | 110 | 165 | |
Weight (kg) | 170 | 190 | 230 | 320 | 360 | 485 | |
Dimension (mm) | Width | 720 | 800 | 1350 | 1400 | 1500 | 1600 |
Height | 600 | 650 | 660 | 700 | 850 | 900 | |
Length | 830 | 950 | 1000 | 1100 | 1140 | 1150 | |
4. machine photo
Zhengzhou Aslan Machinery Co.,Ltd established in 2014 , our company are new in international market ,but we are not new in international market , all member of our company are experienced in international business. Best service, high quality machines are we can service for you. We know we are young but we are confidence, we have more time, more vigor, and more earnest serve for you. Besides that we have powerful supporter, professional technical term together with you and us.
We specialized in machines export and import business. Our products include food machines, agriculture machines, and meat processing machines and so on. For potato processing machine, which include potato harvest machine, potato washing and peeling machine, potato sorting machine and packing machine .For meat processing machine include meat washer, meat chopper, meat bowl cutter, meat tumbler and meat deboning machine, meatball making machine and so on. Quality is our life and your trust is our power. Good cooperating start from trust. We are Looking forward to our cooperation.
•A:Guarantee time is for one year from Machine arrive customer sea port. for every export machine we buy insurance for it . if machine lost or broken during sea freight . we take responsible for it .
Q: During Guarantee time , if machine broken by machine design ,what should we do?
•A:during guarantee time , if machine broken by machine design fault , we talk all responsible , for machine broken part free charge send to you , if after change broken part machine can not work , we send new machine to you .
Q: Which kind documents your company can provided?
•A:after ship depart from China port ,we can get documents from Shipping company such as : bill or lading , insurance documents.packing list , commercial invoice . if you need , we also can apply CO ,FORM F, FORM E etc.
Q:After guarantee time , if we need spare parts , can you provided it ?
•A:we can provided for the machine spare part .
Q:Which kind of package you will use ?
•A:For export , we usually use plywood box . which meet export standard.
